4U rack server, silver front bezel, four drive trays, slide rails included

DELL

DELL PowerEdge R930 rack server 4x Xeon E7-8890 v4 2.2GHz 24-core 768GB DDR4

SKU CH-EWPF-DCSVW

Four-socket 4U rack server with 96 Xeon cores, 768 GB DDR4 ECC memory, PERC H330 RAID controller, quad-port 1/10 GbE networking, iDRAC8 Enterprise, and four 1100 W platinum power supplies

  • Rack Height4U
  • CPU TypeIntel Xeon
  • CPU Speed2.20 GHz
  • CPU SocketLGA 2011
  • Number of CPU Cores24-Core Processor
  • # of Processors Installed4
  • Four 24-core Xeon processors deliver 96 threads for heavy workloads
  • 768 GB DDR4 ECC memory supports large in-memory databases
  • PERC H330 controller provides RAID 0/1/5/10/50 for data protection
  • Quad-port network card adds two 10 Gb SFP+ and two 1 GbE links
  • Four 1100 W 80+ Platinum PSUs give redundant power efficiency

Enterprise 4U rack server

The Dell PowerEdge R930 is a 4U rack server equipped with four Intel Xeon E7-8890 v4 processors, each running at 2.2 GHz with 24 cores. It ships with 768 GB of DDR4 registered ECC memory across 48 DIMM slots. The system includes a PERC H330 storage controller, quad-port networking with two 1 GbE and two 10 Gb SFP+ ports, iDRAC8 Enterprise remote management, four 1100 W power supplies, rails and a front bezel. It targets organisations running memory-intensive databases, virtualisation clusters or ERP workloads.

Build integration

The chassis provides four 2.5-inch drive trays for SATA or SAS devices and supports up to 24 hot-plug drives in total. Ninety-six DDR4 slots allow expansion toward a 12 TB memory ceiling. The H330 controller handles RAID 0, 1, 5, 10 and 50 without an additional card. Quad-port 1 GbE and 10 Gb SFP+ networking is integrated on a daughter card, freeing PCIe slots for further I/O. Four redundant 1100 W platinum power supplies share the load. iDRAC8 Enterprise enables agent-free provisioning and remote console access.

Upgrade perspective

This configuration delivers 96 total cores and 768 GB of memory in a single 4U node, replacing multi-server clusters for in-memory databases such as SAP HANA or large SQL Server instances. The jump is justified when workloads exceed the capacity of two-socket platforms and require the full 12 TB memory headroom. Buyers who need GPU acceleration, direct-attached NVMe beyond the eight-drive front bay limit, or a smaller 1U or 2U footprint should evaluate alternative platforms.

Highlights

  • Four 24-core Xeon processors deliver 96 threads for heavy workloads
  • 768 GB DDR4 ECC memory supports large in-memory databases
  • PERC H330 controller provides RAID 0/1/5/10/50 for data protection
  • Quad-port network card adds two 10 Gb SFP+ and two 1 GbE links
  • Four 1100 W 80+ Platinum PSUs give redundant power efficiency

Specifications

BrandDELL
SeriesPowerEdge R930
Rack Height4U
CPU TypeIntel Xeon
CPU Speed2.20 GHz
CPU SocketLGA 2011
Number of CPU Cores24-Core Processor
# of Processors Installed4
MAX Processors4
ChipsetIntel C602J
Installed Memory Size768GB
Memory TypeDDR4
Max Memory Capacity12TB
Number of Memory Slots96
Storage ControllerDell Perc H330 Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/10/50
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How many processors can the R930 support before reaching its maximum?

The server ships with four Xeon E7-8890 v4 processors installed, which is also the maximum of four sockets the chassis supports.

What is the power supply rating and efficiency for continuous 24/7 operation?

Four 1100W 80+ Platinum power supplies provide redundant power with high efficiency under sustained load.

Which memory generation and form factor must already be on hand to expand the 768GB configuration?

The system uses DDR4 2400MHz registered ECC DIMMs; 48 slots are populated leaving 48 slots free for expansion.
