Silver 2U rack server front with twenty-six 3.5-inch drive bays

DELL

DELL PowerEdge R740xd2 2U rack server 2x Xeon Platinum 8260 2.4GHz 24C 512GB DDR4 26x 4TB SATA HBA330 2x 1100W

SKU CH-E721-3YRSC

2U rack server with dual 24-core Xeon Platinum 8260 CPUs, 512GB DDR4 ECC memory, HBA330 controller and 26× 4TB 7.2K SATA drives

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.4GHz (3.9GHz Turbo)
  • CPU SocketLGA 3647
  • Dual Xeon Platinum 8260 CPUs provide 24 cores each at 2.4 GHz base
  • 512 GB DDR4-2933 ECC memory across 16 slots for data integrity
  • 26 Enterprise 4 TB 7.2K SATA drives deliver massive raw capacity
  • PERC HBA330 12 Gb/s controller manages SAS and SATA storage
  • iDRAC 9 Enterprise plus 10/25 Gb SFP28 and dual 1 GbE networking
  • Redundant 1100 W Platinum PSUs ensure continuous uptime

Dense storage server

The Dell PowerEdge R740xd2 is a 2U rack server built for data-intensive workloads that demand high capacity in a compact footprint. Two Intel Xeon Platinum 8260 processors provide 24 cores each at 2.4GHz with 3.9GHz turbo for parallel compute tasks. 512GB of DDR4 ECC registered memory across 16 slots supports large working sets and data integrity. Twenty-six 3.5-inch drive bays filled with 4TB 7.2K SATA drives deliver raw capacity for archives, backups or software-defined storage clusters.

HBA330 and dual 25Gb networking

The PERC HBA330 controller presents the 26 SATA drives to the operating system without hardware RAID abstraction, which suits ZFS, Ceph or similar software-defined storage stacks that manage redundancy themselves. A Broadcom 57414 dual-port 10/25Gb SFP28 OCP 2.0 mezzanine card adds high-throughput network connectivity for replication or client access. iDRAC 9 Enterprise enables full remote management, power control and firmware updates without physical presence. Dual 1100W platinum power supplies provide redundancy for continuous operation.

26-bay chassis and rail constraints

The 2U chassis holds 26 hot-swap 3.5-inch drives in a dense front-loading layout that maximises storage per rack unit. Redundant hot-swap power supplies and fans allow component replacement without downtime. Front bezel and ready rails are not included, so mounting hardware must be sourced separately for the target rack. The LGA 3647 socket and 16 DIMM slots leave no room for additional processors beyond the two installed, and memory expansion is limited to the 1TB maximum.

Highlights

  • Dual Xeon Platinum 8260 CPUs provide 24 cores each at 2.4 GHz base
  • 512 GB DDR4-2933 ECC memory across 16 slots for data integrity
  • 26 Enterprise 4 TB 7.2K SATA drives deliver massive raw capacity
  • PERC HBA330 12 Gb/s controller manages SAS and SATA storage
  • iDRAC 9 Enterprise plus 10/25 Gb SFP28 and dual 1 GbE networking
  • Redundant 1100 W Platinum PSUs ensure continuous uptime

Specifications

BrandDELL
SeriesPowerEdge
ModelR740xd2
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.4GHz (3.9GHz Turbo)
CPU SocketLGA 3647
Number of CPU Cores24 Core-Processors
CPU FeaturesPlatinum 8260
# of Processors Installed2
MAX Processors2
Installed Memory Size512GB
Memory TypeDDR4
Max Memory Capacity1TB
Number of Memory Slots16
Hard Drive (Installed)26 x 4TB 7.2K SATA
Storage ControllerDell Perc HBA330 Controller
HDD InterfaceSATA
SSD (Installed)No
Raid LevelNone
Ethernet Controller1x Integrated Dual Port 1GbE LOM and 1x Dell EMC Broadcom 57414 Dual Port 10/25Gb SFP28 OCP 2.0 Mezzanine Card
Remote ManagementiDRAC9 Enterprise
LAN Ports4 x Ports
Management PortRJ 45
Operating SystemNo
Features0

Questions about this item

How many of the 26 installed 4 TB SATA drives can be swapped without shutting the server down?

All 26 drives sit in hot-swap bays, so any failed 4 TB SATA unit can be replaced while the system stays online.

Which component reaches its ceiling first when the dual Xeon Platinum 8260 CPUs run at 3.9 GHz turbo continuously?

The 1100 W platinum power supplies set the sustained power envelope, limiting how long both 24-core processors can hold maximum turbo.

What is the typical acoustic and thermal profile when the 2U chassis runs 26 drives and dual 24-core CPUs around the clock?

Dual 1100 W platinum PSUs and high-speed chassis fans keep inlet temperatures within spec, but the system emits noticeable datacentre-grade noise under full load.
