Silver 2U rack server with twelve 3.5-inch drive bays and redundant power supplies

DELL

DELL PowerEdge R730XD 2U rack server E5-2630 v3 2.4GHz 48GB DDR4 3x 2TB SAS H730

SKU CH-SNEE-6BD4T

2U rack server with single Xeon E5-2630 v3 2.4GHz, 48GB DDR4, three 2TB SAS drives and H730 RAID controller

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • MAX Processors2
  • ChipsetIntel C610
  • 2U rack form factor fits dense server rooms
  • Single Intel Xeon E5-2630 v3 eight-core 2.4GHz processor
  • 48GB DDR4 memory across 24 DIMM slots
  • Three 2TB SAS drives with H730 1GB RAID controller
  • Dual 750W redundant hot-swap power supplies

Server identity

The Dell PowerEdge R730XD is a 2U rack server fitted with a single Intel Xeon E5-2630 v3 eight-core processor running at 2.4 GHz. It ships with 48 GB of DDR4 memory across 24 DIMM slots and a Perc H730 RAID controller with 1 GB cache. Three 2 TB 7.2K SAS drives occupy three of the twelve 3.5-inch hot-plug bays, and dual 750 W redundant power supplies are installed. The system includes a DVD-ROM drive and a quad-port 1 GbE daughter card, with no operating system supplied.

Suitable workloads

This configuration suits organisations that need dense 3.5-inch storage in a 2U form factor, hardware RAID across mixed SAS or SATA drives, and redundant power for continuous operation. The single-socket layout and 48 GB memory ceiling limit virtualisation density, so environments requiring two processors or more than 48 GB of RAM should consider a different chassis or a dual-socket build.

Bundled impact

The H730 controller enables RAID 0, 1, 5, 6, 10, 50 and 60 across the installed drives and any future additions, while the hot-plug bays allow drive changes without downtime. Redundant power supplies protect against a single PSU failure. iDRAC8 Express provides out-of-band management from day one, with Enterprise features and vFlash media available as upgrades. The quad 1 GbE ports handle basic network connectivity; 10 GbE options require an additional NDC card.

Highlights

  • 2U rack form factor fits dense server rooms
  • Single Intel Xeon E5-2630 v3 eight-core 2.4GHz processor
  • 48GB DDR4 memory across 24 DIMM slots
  • Three 2TB SAS drives with H730 1GB RAID controller
  • Dual 750W redundant hot-swap power supplies

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge R730XD
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
MAX Processors2
ChipsetIntel C610
Installed Memory Size48GB
Memory TypeDDR4
Max Memory Capacity48GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots24
Storage ControllerDell Perc H730 Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Max HDD Capacity52TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementiDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
LAN Ports4 x Ports
Expansion SlotsUp to 7 x PCIe 3.0 plus dedicated PERC slot
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight70.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What DDR4 DIMM modules do I need to add more memory to the 24 slots?

The server accepts 4GB, 8GB, 16GB, 32GB, 64GB or 128GB DDR4 modules up to 2400MT/s, with actual speed depending on the installed Xeon E5-2630 v3 processor.

Can I keep using my existing 3.5-inch SATA drives in the hot-plug bays?

Yes, the 12 hot-plug bays support both SAS and SATA 3.5-inch drives, so current SATA drives will work alongside the three installed 2TB SAS drives.

How do I confirm the H730 RAID controller is operating at 12Gbps after setup?

Check the controller BIOS or iDRAC8 interface; it will report the negotiated link speed for each attached drive, showing 12Gbps when the SAS drives are running at full rate.
