Silver 2U rack server with twelve 3.5-inch drive bays and redundant power supplies

DELL

DELL PowerEdge R730XD 2U rack server 2× Xeon E5-2609v3 1.9GHz 32GB DDR4 3× 300GB 15K SAS H730

SKU CH-A277-CQADC

A 2U rack server with dual Xeon E5-2609v3 CPUs, 32GB DDR4, three 300GB 15K SAS drives and an H730 RAID controller

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeDual Intel Xeon
  • MAX Processors2
  • ChipsetIntel C610
  • Dual Xeon E5-2609v3 processors deliver 12 cores for multi-threaded workloads
  • 32 GB DDR4 memory supports virtualization and database tasks
  • Three 300 GB 15K SAS drives provide fast sequential access
  • H730 RAID controller enables RAID 0/1/5/6/10/50/60 for data protection
  • Twelve 3.5-inch hot-plug bays allow storage expansion up to 52 TB

Dense 2U storage server

The Dell PowerEdge R730XD fits twelve 3.5-inch hot-plug bays into a 2U rack frame. Dual Xeon E5-2609v3 processors and 32 GB of DDR4 memory provide a balanced compute base for storage-heavy workloads. Three 300 GB 15 K SAS drives and a PERC H730 RAID controller arrive pre-configured. Buyers needing higher core counts or GPU acceleration should look elsewhere.

Dual 750 W redundant supplies

Redundant hot-swap power modules share the load and allow one unit to fail without downtime. The 2U chassis uses front-to-rear airflow across the drive bays and CPU heatsinks. Fan speeds scale with inlet temperature and drive activity. Acoustic output is typical for a rackmount server in a cooled data-centre aisle.

iDRAC8 remote management

The integrated iDRAC8 Express provides out-of-band console, power control and hardware health monitoring over a dedicated network port. Lifecycle Controller automates firmware updates and OS deployment without media. The H730 controller adds 1 GB cache and supports RAID 0, 1, 5, 6, 10, 50 and 60 across all twelve bays. An optical DVD drive is included for legacy installs.

Highlights

  • Dual Xeon E5-2609v3 processors deliver 12 cores for multi-threaded workloads
  • 32 GB DDR4 memory supports virtualization and database tasks
  • Three 300 GB 15K SAS drives provide fast sequential access
  • H730 RAID controller enables RAID 0/1/5/6/10/50/60 for data protection
  • Twelve 3.5-inch hot-plug bays allow storage expansion up to 52 TB

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge R730XD
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeDual Intel Xeon
MAX Processors2
ChipsetIntel C610
Installed Memory Size32GB
Memory TypeDDR4
Max Memory Capacity32GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots24
Storage ControllerDell Perc H730 Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Max HDD Capacity52TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementiDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
LAN Ports4 x Ports
Expansion SlotsUp to 7 x PCIe 3.0 plus dedicated PERC slot
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight70.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I install additional DDR4 memory modules in the 24 DIMM slots, and which step is often missed?

Populate slots evenly across the 12 channels per processor, matching identical capacities per channel; the step often missed is balancing each CPU's 12 slots so memory runs at up to 2400MT/s.

What maintenance will the three 300GB 15K SAS drives and H730 controller need over time?

Monitor SMART data via the H730 for reallocated sectors on the 15K SAS drives; replace any drive that exceeds the controller's error threshold to keep RAID 0/1/5/6/10/50/60 healthy.

What is the first limit reached under sustained load with the dual E5-2609v3 CPUs and 750W redundant power supplies?

The 1.9GHz six-core CPUs hit thermal throttling before the 750W redundant supplies reach capacity, so sustained compute throughput is capped by processor cooling headroom.
