Silver 2U rack server front with 24 drive bays

DELL

DELL PowerEdge R730XD 2U rack server 2× E5-2630 v3 2.4GHz 32GB DDR4 3× 900GB SAS H730

SKU CH-XZ16-K22CA

2U rack server with dual Xeon E5-2630 v3 CPUs, 32 GB DDR4, three 900 GB 10K SAS drives and H730 RAID controller

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeDual Intel Xeon
  • MAX Processors2
  • ChipsetIntel C610

Installed Memory Size 32GB

HDD 3 x 900GB

  • Dual Xeon E5-2630 v3 CPUs deliver 16 cores for multi-threaded workloads
  • 32 GB DDR4 memory supports up to 1 536 GB across 24 DIMM slots
  • Three 900 GB 10K SAS drives provide fast hot-plug storage
  • PERC H730 RAID controller enables RAID 0/1/5/6/10/50/60 with 1 GB cache
  • Dual 750 W redundant power supplies keep the 2U chassis running

Dense 2U Storage Server

The Dell PowerEdge R730XD fits dual Xeon E5-2630 v3 processors and 32 GB of DDR4 into a 2U rack chassis with 24 hot-plug 2.5-inch bays. Three 900 GB 10K SAS drives and a PERC H730 controller with 1 GB cache provide hardware RAID 0, 1, 5, 6, 10, 50 and 60. Dual 750 W redundant supplies and iDRAC8 remote management complete the platform.

Buyers Needing Mass Drive Density

This server targets environments that prioritise internal capacity over raw compute, such as backup repositories, software-defined storage nodes or archival workloads. The 24-bay layout and SAS/SATA flexibility suit those use cases. Builders who require more than two processors, PCIe 4.0 links or GPU-ready power budgets should evaluate alternative platforms.

24 Hot-Plug 2.5-Inch Bays

The defining constraint is the front-loading bay count: twenty-four 2.5-inch slots share the 2U height, limiting each drive to 15 mm thickness and capping total raw SAS capacity at 52 TB. If the workload demands more spindles or 3.5-inch form factors, a different chassis is required.

Highlights

  • Dual Xeon E5-2630 v3 CPUs deliver 16 cores for multi-threaded workloads
  • 32 GB DDR4 memory supports up to 1 536 GB across 24 DIMM slots
  • Three 900 GB 10K SAS drives provide fast hot-plug storage
  • PERC H730 RAID controller enables RAID 0/1/5/6/10/50/60 with 1 GB cache
  • Dual 750 W redundant power supplies keep the 2U chassis running

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge R730XD
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeDual Intel Xeon
MAX Processors2
ChipsetIntel C610
Installed Memory Size32GB
Memory TypeDDR4
Max Memory Capacity32GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots24
Storage ControllerDell Perc H730 Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Max HDD Capacity52TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementiDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
LAN Ports4 x Ports
Expansion SlotsUp to 7 x PCIe 3.0 plus dedicated PERC slot
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight70.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much RAM can the 24 DIMM slots actually hold with these E5-2630 v3 CPUs?

The installed CPUs limit total memory to 32GB despite the 24 slots supporting up to 1536GB with other processors.

What is the sustained power draw when both 750W supplies run the dual 2.4GHz CPUs and 24 drive bays continuously?

Dual 750W redundant supplies handle the two 8-core CPUs, 32GB DDR4, H730 controller and up to 24 SAS drives under full load.

Which rack rails and cable-management arms fit the 26.8-inch deep 2U chassis?

Standard Dell 2U sliding rails for 26.8-inch depth chassis are required; cable-management arm matches the same rail kit.
