Silver 2U rack server with eight 3.5-inch drive bays and front bezel

DELL

DELL PowerEdge R540 2U rack server 2x Xeon Silver 4114 2.2GHz 10-core 64GB DDR4 8x 4TB SAS H730P

SKU CH-8NRY-JFFZA

2U rack server with dual 10-core Xeon Silver 4114 CPUs, 64 GB DDR4, eight 4 TB SAS drives on an H730P controller, dual 750 W power supplies and iDRAC9 Enterprise

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.20 GHz
  • CPU SocketLGA 3647
  • 20 cores at 2.2 GHz with 3.0 GHz turbo power demanding workloads
  • 64 GB DDR4 2666 MHz ECC memory supports large virtualised environments
  • PERC H730P 2 GB controller enables RAID 0, 1, 5, 6, 10, 50, 60
  • Eight 4 TB 7.2K SAS drives provide high-capacity enterprise storage
  • Dual 750 W 80+ Platinum PSUs with iDRAC9 Enterprise ensure resilient management

Dell PowerEdge R540 2U server

The Dell PowerEdge R540 is a 2U rack server built for virtualization, database hosting and business-critical workloads. Dual Intel Xeon Silver 4114 processors provide 20 cores at 2.20 GHz with 3.0 GHz turbo. 64GB DDR4 2666MHz registered ECC memory and eight 4TB 7.2K SAS drives deliver capacity and reliability. iDRAC 9 Enterprise enables remote management.

Who this suits and who should look elsewhere

This server fits teams running multi-threaded applications, file services or virtual machines that benefit from high core counts and large SAS storage arrays. Redundant 750W power supplies and hot-swap bays support continuous operation. Buyers needing GPU compute or more than two processor sockets should evaluate other platforms.

The specification that decides fit

The PERC H730P controller supports RAID 0/1/5/6/10/50/60 with 2GB cache and battery backup. Confirm your workload requires SAS 12Gb/s connectivity and this RAID feature set before purchasing.

Highlights

  • 20 cores at 2.2 GHz with 3.0 GHz turbo power demanding workloads
  • 64 GB DDR4 2666 MHz ECC memory supports large virtualised environments
  • PERC H730P 2 GB controller enables RAID 0, 1, 5, 6, 10, 50, 60
  • Eight 4 TB 7.2K SAS drives provide high-capacity enterprise storage
  • Dual 750 W 80+ Platinum PSUs with iDRAC9 Enterprise ensure resilient management

Specifications

BrandDELL
SeriesPowerEdge
ModelR540
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.20 GHz
CPU SocketLGA 3647
Number of CPU Cores10-Core Processor
CPU FeaturesSilver 4114
# of Processors Installed2
MAX Processors2
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity1TB
Number of Memory Slots16
Hard Drive (Installed)8 x 4TB 7.2K SAS
Storage ControllerDell Perc H730P 2GB Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Ethernet Controller1x Dell EMC Integrated Dual Port Network Daughter Card - 2x 1 Gigabit RJ45 Ports,
Remote ManagementDell EMC 14G PowerEdge iDRAC 9 Enterprise License
LAN Ports2 x Ports
Management PortRJ 45
Operating SystemNo

Questions about this item

How do I verify the PERC H730P controller sees all eight 4 TB SAS drives after setup?

Open the controller BIOS during boot or log into iDRAC9 Enterprise; the storage view should list eight 4 TB 7.2K SAS disks and show the RAID array status as optimal.

What ships with the server and what must I source separately?

The box contains the 2U chassis, dual Xeon Silver 4114 CPUs, 64 GB DDR4 ECC memory, H730P 2 GB controller, eight 3.5" 4 TB SAS drives, dual 750 W PSUs, rails, bezel and iDRAC9 Enterprise; an operating system is not included.

Should I choose the 64 GB DDR4 configuration or plan for more memory later?

The system has 16 DIMM slots and supports up to 1 TB; starting with 64 GB (4×16 GB) leaves 12 free slots for future expansion without removing existing modules.
