Green circuit board with silver heatsink and gold edge connector

DELL

DELL PERC H730P SAS SATA RAID Controller 12GBps PCI-Express 3.0 x8 2GB

SKU CH-Z1XC-M8Z87

Adds 2 GB cache to server RAID arrays with 12 Gbps SAS and SATA connectivity over PCIe 3.0 x8

  • InterfacePCI-Express
  • 12 GBps SAS SATA throughput for fast data handling
  • PCI-Express 3.0 x8 interface delivers high bandwidth
  • 2 GB cache memory boosts RAID performance
  • Dell PERC H730P controller built for server reliability
  • Expandable design supports growing storage needs

RAID Controller for Dell Servers

The Dell PERC H730P is a hardware RAID controller designed for Dell PowerEdge servers. It connects through a PCI-Express 3.0 x8 slot and provides 12Gbps SAS and SATA connectivity with 2GB of onboard cache to accelerate storage arrays.

Suited For And Limitations

This card suits administrators expanding or replacing storage controllers in compatible Dell server platforms that accept the mini blade form factor. It is not suited for systems that lack a PCI-Express 3.0 x8 slot or for environments requiring host bus adapter firmware instead of RAID functionality.

Deciding Specification

The controller operates on a PCI-Express 3.0 x8 interface and delivers 12Gbps SAS and SATA throughput. Verify that the target server chassis supports this slot width and generation before purchase.

Highlights

  • 12 GBps SAS SATA throughput for fast data handling
  • PCI-Express 3.0 x8 interface delivers high bandwidth
  • 2 GB cache memory boosts RAID performance
  • Dell PERC H730P controller built for server reliability
  • Expandable design supports growing storage needs

Specifications

BrandDell
Part NumberYRPP6
InterfacePCI-Express

Questions about this item

How do I confirm the PERC H730P controller is operating at 12GBps after installation?

Check the controller BIOS during POST or use the Dell OpenManage utility to verify the negotiated link speed shows 12GBps on each connected SAS or SATA drive.

What comes with the YRPP6 card and what must I source separately?

The controller card is supplied alone; you will need compatible SAS or SATA cables, a 2GB cache module if not pre-fitted, and a server chassis with a PCI-Express 3.0 x8 slot.

Which part number should I order — YRPP6 or 0YRPP6?

Both numbers refer to the same PERC H730P hardware; choose the one that matches your procurement system or the listing on your invoice.
