Blue laptop motherboard with mounted Xeon processor and four DDR4 memory slots

DELL

DELL CAP00 Precision 7520 Motherboard Xeon E3-1545M v5 2.90GHz

SKU CH-PCRF-EPXT5 MPN CAP00

Replacement laptop motherboard for Dell Precision 7520 with Xeon E3-1545M v5 processor at 2.90GHz and four DDR4 memory slots supporting up to 64GB

  • ColorBlue
  • Built for Dell Precision 7520 workstations
  • Xeon E3-1545M v5 runs at 2.90GHz with 3.80GHz turbo
  • Intel CM238 chipset manages I/O and memory
  • Four DDR4 slots support up to 64GB RAM
  • Genuine Dell part JYFWJ matches 451A4X31L23

Dell Precision 7520 Motherboard

This replacement motherboard integrates an Intel Xeon E3-1545M v5 processor running at 2.90GHz with a 3.80GHz maximum turbo frequency. It is designed specifically for the Dell Precision 7520 Series mobile workstations. The board uses the Intel CM238 chipset and arrives in new condition.

Fits Dell Precision 7520 chassis using part number

The board provides four memory slots supporting DDR4 SDRAM at 2667MHz or 2400MHz, allowing up to 32GB at the higher speed or 64GB at the lower speed. It replaces the original system board directly without requiring additional adapters or cables. No accessories are included with the unit.

Suits technicians restoring a Precision 7520

Builders needing a different socket, chipset, or memory configuration cannot use this board. It is not a bare board for custom assembly; the processor is already soldered in place. Buyers should verify the exact part number against their original hardware before ordering.

Highlights

  • Built for Dell Precision 7520 workstations
  • Xeon E3-1545M v5 runs at 2.90GHz with 3.80GHz turbo
  • Intel CM238 chipset manages I/O and memory
  • Four DDR4 slots support up to 64GB RAM
  • Genuine Dell part JYFWJ matches 451A4X31L23

Specifications

BrandDell
ModelPrecision 7520
Part NumberJYFWJ
ColorBlue

Questions about this item

Does the Xeon E3-1545M v5 throttle at 3.80GHz under sustained load?

The processor runs at 2.90GHz base and can reach 3.80GHz Max Turbo; actual sustained speed depends on the laptop cooling solution.

How hot or loud does the CAP00 LA-E311P board get during all-day operation?

The motherboard itself has no fans; thermal output and noise come from the Precision 7520 chassis cooling design.

Which memory modules must I already own to populate the four slots?

You need DDR4 SDRAM sticks rated for 2400MHz or 2667MHz, up to 32GB at 2667MHz or 64GB at 2400MHz total.
