Green rectangular circuit board with silver SFP+ cages and gold RJ45 ports

DELL

DELL Broadcom 57142 2x10GBe SFP+ 2x1GBe RJ45 Network Daughter Card

SKU CH-1P47-1GG7F

Adds two 10 Gb SFP+ and two 1 Gb RJ45 ports via a PCI-Express daughter card

  • Speed10Gbps
  • InterfacePCI-Express
  • Dual 10 Gbps SFP+ ports deliver high-throughput server links
  • Dual 1 Gbps RJ45 ports provide standard copper connectivity
  • Broadcom 57142 controller ensures reliable packet processing
  • PCI-Express interface enables fast host communication
  • Compact daughter-card form factor fits dense server chassis

Dell Broadcom 57142 Quad-Port Network Card

This Dell Broadcom 57142 daughter card adds four wired network ports to a compatible server. It provides two 10Gbps SFP+ ports and two 1Gbps RJ45 ports through a single PCI-Express slot. The compact plug-in design suits high-performance server applications.

Practical Limits of PCI-Express and SFP+

The card uses a PCI-Express interface, so total throughput depends on the slot generation and lane count available in the host system. Each 10Gbps SFP+ port requires a compatible transceiver module and fibre or direct-attach cable, which are not included. The 1Gbps RJ45 ports work with standard Cat5e or better copper cabling.

Replaces Single-Port or Slower Adapters

This quad-port card replaces multiple single-port adapters, freeing expansion slots and reducing cabling complexity. The jump is worth it when a server needs both 10Gbps uplinks and 1Gbps management or backup links simultaneously. It is not for systems lacking a compatible PCI-Express slot or for buyers who need more than four ports.

Highlights

  • Dual 10 Gbps SFP+ ports deliver high-throughput server links
  • Dual 1 Gbps RJ45 ports provide standard copper connectivity
  • Broadcom 57142 controller ensures reliable packet processing
  • PCI-Express interface enables fast host communication
  • Compact daughter-card form factor fits dense server chassis

Specifications

BrandDell
Part NumberNWMNX
Speed10Gbps
InterfacePCI-Express

Questions about this item

Should I choose the 10 Gbps SFP+ ports or the 1 Gbps RJ45 ports for my server uplink?

Use the two 10 Gbps SFP+ ports for high-throughput uplinks to core switches. The two 1 Gbps RJ45 ports suit management traffic or legacy copper links. Both pairs operate simultaneously on the same Broadcom 57142 controller.

What does the 10 Gbps rating deliver inside a rack server?

The card provides two 10 Gbps SFP+ lanes and two 1 Gbps RJ45 lanes through a single PCI-Express slot. Aggregate throughput depends on the host bus width and CPU offload, but each SFP+ port can sustain line-rate 10 Gbps with supported transceivers.

Which PCI-Express generation does the NWMNX card use and what bandwidth ceiling does that impose?

The adapter plugs into a standard PCI-Express slot. The Broadcom 57142 controller negotiates the link speed supported by the server platform, so the practical ceiling matches the slot generation installed in your chassis.
