Transparent rectangular overload relay with front-mounted controls and terminal markings

Dayton

Dayton 6ECA2 Overload Relay 63-80A Trip Class 10

SKU CH-7YFG-X0FT4

Thermal overload relay protects motors with adjustable 63-80 A range and Trip Class 10 response

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Thermal overload protection covers 63 to 80 A
  • Trip Class 10 ensures fast response to faults
  • Dual 1NO/1NC auxiliary contacts simplify control wiring
  • Direct contactor mounting reduces panel space needed
  • IEC 60947-4-1, CSA and UL listed for compliance

63-80 A Overload Relay for Motor Protection

The Dayton 6ECA2 is a three-pole thermal overload relay designed to protect motors by interrupting the circuit when current exceeds the set threshold. It offers an adjustable trip range from 63 A minimum to 80 A maximum, suitable for industrial control panels and automation systems. The unit mounts directly to a contactor and complies with IEC 60947-4-1, CSA and UL Listed standards. Trip Class 10 provides a standard response time for general-purpose motor loads.

Thermal Operation and Power Characteristics

Thermal overload protection reacts to sustained overcurrent by heating an internal element, so the relay trips without external power or electronic sensors. Trip Class 10 defines the maximum tripping time at 7.2 times the current setting, giving predictable behaviour during motor start-up. The device carries both 1NO and 1NC auxiliary contacts for signalling or interlocking. Auto and manual reset modes let maintenance staff choose the recovery method after a fault.

Direct Contactor Mounting and Compliance Benefits

Direct-to-contactor mounting eliminates separate DIN-rail hardware and reduces panel wiring time. The compact body measures 4.29 in deep, 2.75 in wide and 2.12 in high, fitting tight enclosures. California Proposition 65 warnings apply because the product contains listed chemicals, a factor for installers in regulated jurisdictions. No additional accessories or software are bundled with this relay.

Highlights

  • Thermal overload protection covers 63 to 80 A
  • Trip Class 10 ensures fast response to faults
  • Dual 1NO/1NC auxiliary contacts simplify control wiring
  • Direct contactor mounting reduces panel space needed
  • IEC 60947-4-1, CSA and UL listed for compliance

Specifications

BrandDAYTON
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

How is the Dayton 6ECA2 overload relay mounted, and what step is often missed?

It mounts direct to the contactor; the step often missed is verifying the contactor matches the relay's 3-pole IEC frame before tightening the mounting screws.

What maintenance or replacement will the 63-80 A thermal overload relay need later?

The thermal element may drift over time; plan to recalibrate or replace the relay if nuisance trips appear after extended service.

What limit appears first on the 6ECA2 during sustained overload at Trip Class 10?

The thermal element reaches its Trip Class 10 curve first, opening the 1NO/1NC auxiliary contacts to protect the motor circuit.
