Dayton

Dayton 6E816 High Temperature Air Curtain Blower 5250 FPM

SKU CH-P6KR-EKS61

Delivers up to 5,250 FPM airflow across doorways up to 5 ft wide and 12 ft high with a 1 hp three-phase motor

  • typeHigh Temperature
  • High-velocity 5,250 FPM airflow creates an effective barrier
  • 1 hp three-phase motor delivers reliable performance
  • Two-speed operation allows adjustable air output
  • Galvanised steel housing in 24 ga gauge resists corrosion
  • Mounts up to 12 ft high for doorways up to 5 ft wide

High-Temperature Air Curtain Blower

The Dayton 6E816 high-temperature air curtain blower delivers a 5250 FPM airstream across doorways up to 5 ft wide with mounting heights up to 12 ft. It suits commercial and industrial entrances that need a durable barrier against outside air, dust and insects.

Upgrade from single-speed units

This assembly replaces single-speed or lower-velocity curtains where two-speed control and a 1 hp three-phase motor provide stronger airflow. The jump is worthwhile when door traffic demands 3,930 cfm through a 36 in cabinet or up to 4,585 cfm through a 42 in cabinet for effective climate separation.

Verify three-phase power and dimensions

Confirm your supply matches 208-230/460 V AC three-phase power before ordering. Ensure the 35 in overall width, 10 3/4 in height and 11 in depth fit the mounting space, and that the 24 ga galvanized steel housing meets the environmental requirements of the installation site.

Highlights

  • High-velocity 5,250 FPM airflow creates an effective barrier
  • 1 hp three-phase motor delivers reliable performance
  • Two-speed operation allows adjustable air output
  • Galvanised steel housing in 24 ga gauge resists corrosion
  • Mounts up to 12 ft high for doorways up to 5 ft wide

Specifications

BrandDayton
typeHigh Temperature

Questions about this item

What ceiling opening and mounting height does the 35-inch wide, 10 3/4-inch high blower require?

The unit measures 35 inches wide, 10 3/4 inches high and 11 inches deep, and is rated for mounting heights up to 12 feet above a doorway up to 5 feet wide.

How is the three-phase motor wired on-site, and what step do installers often miss?

Connect the 208-230/460 V AC three-phase supply to the motor terminals and verify rotation direction; the step often missed is confirming the blower spins the correct way before securing the cabinet.

Which components need periodic inspection on this 1 hp, two-speed galvanised steel assembly?

Check the motor bearings, belt tension (if belt-driven), and the 24-gauge galvanised steel housing for corrosion or debris buildup at least annually.
