Transparent square encapsulated relay with screw terminals and potentiometer adjustment

Dayton

Dayton 5WML8 Off Delay Timing Relay 125V DC .5-10s

SKU CH-AXCZ-861GV

An encapsulated timing relay provides a single off-delay function adjustable from .5 to 10 seconds for 12 to 125V DC circuits

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Off-delay function provides controlled shutdown timing
  • Adjustable .5 to 10 second delay range via potentiometer
  • 125V DC coil voltage suits industrial control circuits
  • SPST-NO contact rated 1 A at 12 to 125V DC
  • Encapsulated square base with screw terminals for surface mounting

Dayton 5WML8 Off Delay Relay

This Dayton 5WML8 is a single-function encapsulated timing relay built for industrial electrical control and automation. It provides an off-delay function with a coil voltage of 125V DC and a contact rating of 1 A at 12 to 125V DC.

Installing the square base relay

The unit mounts on a surface using screw terminals for electrical connection and a potentiometer for time adjustment. Wiring must match the five-pin layout and the 12 to 125V DC input range to avoid coil damage or timing errors.

Suited for simple off-delay circuits

It suits panels needing one adjustable off-delay between .5 and 10 seconds with SPST-NO contacts. Builders requiring on-delay, multiple functions, AC contact ratings or different voltage ranges should look at other relays.

Highlights

  • Off-delay function provides controlled shutdown timing
  • Adjustable .5 to 10 second delay range via potentiometer
  • 125V DC coil voltage suits industrial control circuits
  • SPST-NO contact rated 1 A at 12 to 125V DC
  • Encapsulated square base with screw terminals for surface mounting

Specifications

BrandDAYTON
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

How do I verify the relay operates correctly after wiring it?

Apply 125V DC to the coil, trigger the input, then measure the output with a multimeter; the contact should stay closed for the potentiometer-set interval between .5 and 10 seconds before opening.

What ships with the unit and what must I source separately?

The encapsulated relay with five screw terminals is supplied; you must provide 12 to 125V DC power, control wiring and a mounting surface.

Which timing version should I select for a specific off-delay range?

This model covers .5 to 10 seconds in a single 125V DC SPST-NO unit; choose it when your application falls inside that window.
