Transparent octal relay with eight flat pins and potentiometer adjustment

Dayton

Dayton 5WMK2 Off Delay Relay 24V 10A 30min

SKU CH-WXH0-4HJC8

Provides a single power-off delay function adjustable from 0.05 seconds to 30 minutes with a 24V AC/DC coil and DPDT contacts rated at 10 A

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Adjustable timing from 0.05 seconds up to 30 minutes
  • True off-delay function keeps circuit active after power removal
  • DPDT contacts rated 10 amps at 240 volts AC
  • Operates on 24 volts AC or DC coil voltage
  • Enclosed octal base with IP20 protection rating

Dayton 5WMK2 Off Delay Relay 24V 10A 30min

The Dayton 5WMK2 is a single-function off-delay relay designed for industrial electrical controls and automation. It features an octal base with eight pins and a transparent enclosed housing rated IP20. The relay operates on a 24V AC/DC coil voltage and provides a true off-delay timing function adjustable via potentiometer from 0.05 seconds up to 30 minutes.

Installers needing a true power-off delay

This relay suits control panels, motor circuits and lighting systems that require a load to remain energised for a set period after the control signal is removed. The DPDT contact form rated at 10 A at 240V AC and 8 A at 28V DC handles moderate resistive and inductive loads. Buyers who need multiple timing functions, on-delay operation or programmable logic control should look at alternative devices.

Fits standard octal sockets for panel mounting

The eight-pin octal base plugs into industry-standard sockets, simplifying installation and replacement without rewiring. The potentiometer adjustment is accessible on the face for quick time setting changes. The enclosed IP20 housing protects internal contacts from dust and incidental contact, freeing up space inside the enclosure by eliminating the need for a separate protective cover.

Highlights

  • Adjustable timing from 0.05 seconds up to 30 minutes
  • True off-delay function keeps circuit active after power removal
  • DPDT contacts rated 10 amps at 240 volts AC
  • Operates on 24 volts AC or DC coil voltage
  • Enclosed octal base with IP20 protection rating

Specifications

BrandDAYTON
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

What socket do I need to mount the 8-pin octal base of the Dayton 5WMK2?

The relay uses an octal socket that accepts eight flat pins; any standard 8-pin octal socket will accept the base.

Can the DPDT contacts switch a 240 V AC load while the coil runs on 24 V AC/DC?

Yes, the contacts are rated 10 A at 240 V AC and the coil operates on 24 V AC/DC, so the two circuits are independent.

How do I verify the off-delay timing is correct after wiring the relay?

Apply 24 V to the coil, then remove power; the contacts should stay closed for the potentiometer setting up to 30 min before opening.
