Dayton 3PU18 solenoid valve coil with junction box enclosure and 18 inch leads

Dayton

Dayton 3PU18 Solenoid Valve Coil 24VDC 4W

SKU CH-1DY6-5AJF3

A 24 V DC solenoid coil rated at 4 watts with a NEMA 1 junction-box enclosure and 18-inch leads

  • TypeDrain Components
  • 24 V DC operation suits low-voltage control circuits
  • 4 W power draw keeps energy use low
  • Class F insulation handles higher operating temperatures
  • 18 in leads simplify wiring in tight spaces
  • UL Listed for verified safety compliance

Solenoid Valve Coil 24VDC

This Dayton 3PU18 solenoid valve coil operates at 24 V DC and consumes 4 W. It is designed for use with compatible drain and trap components in plumbing systems. The coil carries a UL Listed rating for safety compliance.

Capacity and headroom

The coil draws an inrush current of 60 VA and a holding current of 5 VA. Its Class F insulation handles typical operating temperatures for drain applications. Continuous duty beyond the rated voltage or current will exceed its design limits.

Integration into a build

The unit includes a NEMA 1 rated junction box enclosure with 18 in. lead wires for direct electrical connections. An inner hole diameter of 1 5/16 in. and height of 1 1/4 in. determine valve compatibility. It is not suited for installations requiring higher NEMA ratings or different voltage supplies.

Highlights

  • 24 V DC operation suits low-voltage control circuits
  • 4 W power draw keeps energy use low
  • Class F insulation handles higher operating temperatures
  • 18 in leads simplify wiring in tight spaces
  • UL Listed for verified safety compliance

Specifications

TypeDrain Components
BrandDayton
Model3PU18

Questions about this item

Will the 18 in. leads on this Dayton 3PU18 coil reach the terminal strip on my existing valve without splicing?

The coil ships with 18 in. leads, so measure from the valve's coil pocket to your terminal strip; if the run is longer you will need to extend the wires.

How can I confirm the 24 V DC coil is energised correctly after installation?

Apply 24 V DC and verify the valve actuates; the coil draws 4 W holding and shows a 60 VA inrush, so a brief current spike at power-on is normal.

Does the 3PU18 include the NEMA 1 junction-box enclosure or must I order it separately?

The enclosure is included with the coil, so no separate enclosure purchase is required for this assembly.
