Dayton
Dayton 36VE93 3-Phase Motor 1 HP 182/4 Frame 230/460V AC
Three-phase general-purpose motor delivering 1 HP at 1170 RPM in an 182/4 frame with 230/460 V AC dual-voltage operation and 82.5 % nominal efficiency
- TypeMotors
- 1 HP three-phase power for industrial equipment
- 230/460 V dual-voltage suits common plant supplies
- 1170 RPM six-pole speed matches fan and pump loads
- 5 % nominal efficiency lowers running cost
- Open drip-proof steel frame with conduit box for clean indoor mounting
Three-Phase General Purpose Motor
The Dayton 36VE93 is a 1 HP three-phase AC motor built for continuous-duty industrial and commercial equipment. Its rigid steel frame and open drip-proof enclosure suit conveyors, pumps, fans and similar machinery where reliable, long-running operation is required.
Dual-Voltage 230/460 V AC Operation
The motor runs on either 230 V or 460 V three-phase supply at 60 Hz, drawing 2.5 A at the lower voltage and 1.2 A at the higher voltage. This dual-voltage design lets installers match the motor to the available plant power without a separate transformer.
Class F Insulation With 1.15 Service Factor
Rated for a maximum ambient temperature of 40 °C, the Class F insulation and 1.15 service factor provide thermal margin for sustained full-load running. Ball bearings and the absence of internal thermal protection keep the mechanical design simple for standard industrial environments.
Highlights
- 1 HP three-phase power for industrial equipment
- 230/460 V dual-voltage suits common plant supplies
- 1170 RPM six-pole speed matches fan and pump loads
- 5 % nominal efficiency lowers running cost
- Open drip-proof steel frame with conduit box for clean indoor mounting
Specifications
| Brand | DAYTON |
|---|---|
| Type | Motors |
Questions about this item
What does the 1170 RPM nameplate speed mean when the motor is under load?
The 1170 RPM nameplate rating is the full-load speed; the motor will run at approximately that speed when delivering its rated 1 HP output on a 60 Hz supply.
How does the 230/460 V dual-voltage rating affect the current draw and wiring?
At 230 V the motor draws 2.5 A full-load amps; at 460 V it draws 1.2 A, so the installer must wire the internal leads for the chosen voltage before connecting power.
What mounting and clearance requirements apply to the 182/4 frame with rigid base?
The motor uses a standard NEMA 182/4 rigid base with steel frame; it bolts to a flat surface and needs enough space around the open drip-proof enclosure for airflow at up to 40 °C ambient.
