Clear vinyl coated galvanized steel cable on spool

Dayton

Dayton 33RF83 1/16 in 7 x 7 vinyl coated cable 500 ft

SKU CH-X9ZD-37RY5

Galvanised steel 7×7 cable with clear vinyl coating, 500 ft long, rated for 96 lb working load and 480 lbf breaking strength

  • TypeWheelbarrows & Carts
  • Clear vinyl coating protects the galvanised steel core
  • 7 x 7 strand construction gives flexibility for lifting tasks
  • 96 lb working load limit suits light-duty rigging
  • 480 lbf breaking strength provides a 5:1 safety factor
  • 500 ft continuous length reduces the need for splices

1/16 in Vinyl-Coated Cable for Lifting

This 500 ft galvanized steel cable has a 7 x 7 strand construction with a clear vinyl coating. It carries a 96 lb working load limit and a 480 lbf breaking strength. The overall diameter is 1/8 in with plain ends for custom termination. It is sold new for general lifting applications.

Replaces Worn or Uncoated Wire Rope

Upgrade when existing rope shows corrosion, fraying, or lacks protective coating for outdoor exposure. The vinyl layer reduces abrasion on pulleys and sheaves compared to bare galvanized strands. The jump is worth it when a 96 lb working load meets the task and a 500 ft continuous length avoids splices.

Fits Winches, Pulleys and Custom Rigging

Plain ends allow swaging, clamping or knotting to match hardware on site. The 7 x 7 classification balances flexibility with adequate strength for light hoisting. The coating adds 1/16 in to the wire diameter, so verify groove and fairlead dimensions before installation. Not suited where higher working loads or uncoated wire are specified.

Highlights

  • Clear vinyl coating protects the galvanised steel core
  • 7 x 7 strand construction gives flexibility for lifting tasks
  • 96 lb working load limit suits light-duty rigging
  • 480 lbf breaking strength provides a 5:1 safety factor
  • 500 ft continuous length reduces the need for splices

Specifications

BrandDAYTON
TypeWheelbarrows & Carts

Questions about this item

What diameter pulley or fairlead do I need for the 1/8 in overall diameter?

Use a pulley or fairlead sized for at least 1/8 in overall diameter; the vinyl coating brings the coated cable to 1/8 in while the bare steel is 1/16 in.

How do I attach the plain ends without weakening the 480 lbf breaking strength?

Swage or crimp properly rated sleeves onto the plain ends; do not knot the vinyl-coated 7 x 7 construction because knots reduce the rated strength.

When should I replace the 500 ft reel if the vinyl coating shows cracks?

Replace the cable once the clear vinyl coating cracks or peels, exposing the galvanized steel core to corrosion that lowers the 96 lb working load limit.
