White industrial ceiling fan with four metal blades and a central motor housing, shown mounted overhead

Dayton

Dayton 2LY99 20" Non-Oscillating Industrial Ceiling Fan

SKU CH-Y64E-6NMJV

A 20-inch non-oscillating industrial ceiling fan delivering up to 3700 CFM on high speed with a 1/8 hp permanent split capacitor motor

  • styleNon-oscillating
  • typeCommercial
  • Moves air up to 3700 CFM on high speed
  • Two-speed motor runs at 1200 or 1000 RPM
  • Direct-drive 1/8 HP permanent split capacitor motor
  • Mounts on ceiling or wall for flexible placement
  • Operates up to 104 °F ambient temperature

20-Inch Non-Oscillating Industrial Ceiling Fan

This Dayton 2LY99 ceiling fan is built for light-duty industrial air circulation. The steel construction supports stationary, non-oscillating operation with a 20-inch blade diameter and an overall outside diameter of 23 inches. It mounts to ceilings or walls and runs on 120V AC single-phase power at 60 Hz. Two-speed settings deliver 3700 CFM on high and 2600 CFM on low.

Suited for Warehouses

The fan suits warehouses, workshops, garages and similar commercial spaces that need focused airflow from a fixed position. Buyers who need oscillating motion to sweep air across a wider area should look at other models. The 72 dBA sound level at high speed may be too loud for quiet offices or residential rooms. The maximum ambient temperature rating is 104 degrees Fahrenheit.

Ceiling or Wall Mount Direct Drive Two-Speed Motor

Installation requires a ceiling or wall mounting location with a 120V AC supply. The direct-drive permanent split capacitor motor eliminates belts and runs at 1200 RPM on high and 1000 RPM on low. High speed draws 2.0 amps and 240 watts while low speed draws 1.5 amps and 175 watts. The unit height is 29 1/4 inches, so verify clearance before mounting.

Highlights

  • Moves air up to 3700 CFM on high speed
  • Two-speed motor runs at 1200 or 1000 RPM
  • Direct-drive 1/8 HP permanent split capacitor motor
  • Mounts on ceiling or wall for flexible placement
  • Operates up to 104 °F ambient temperature

Specifications

BrandDayton
styleNon-oscillating
typeCommercial

Questions about this item

What electrical supply does the Dayton 2LY99 require to operate?

The fan runs on a 120 V AC, single-phase, 60 Hz circuit and draws 2.0 amps on high speed or 1.5 amps on low speed.

Can I keep using my existing 20-inch mounting hardware with this 23-inch outside-diameter unit?

The fan’s outside diameter is 23 inches and its height is 29 1/4 inches, so any ceiling or wall bracket must accommodate those dimensions.

How can I confirm the fan is moving air at the rated 3,700 CFM on high speed?

Measure airflow at 20 feet from the unit; the factory spec lists an air velocity of 400 feet per minute on high and 350 on low.
