Dayton
Dayton 24EN99 Time Delay Relay Octal On Delay 12V DPDT 10A
Octal on-delay relay with 0.05 to 5 second timing range, 12 V DC coil and 10 A DPDT contacts
- Adjustable timing from 0.05 to 5 seconds with potentiometer control
- DPDT contacts switch 10 A at 240 V AC or 30 V DC
- 12 V DC coil voltage suits low-voltage control circuits
- Octal 8-pin plug-in base enables quick socket mounting
- IP20 enclosed housing protects internal components
Single-Function On-Delay Relay
The Dayton 24EN99 is a single-function on-delay relay designed for 12 V DC control circuits. It mounts in an octal socket and provides a DPDT contact arrangement for switching separate loads. The unit suits automation panels, machinery sequences and industrial timing tasks that require a single adjustable delay.
Enclosed IP20 Housing
The relay body is fully enclosed with an IP20 rating and measures 1.7 in depth behind the socket. Contacts are rated at 10 A for both 240 V AC and 30 V DC, so normal switching stays within modest thermal limits. No forced cooling is required and the sealed construction keeps dust off the contacts during continuous operation.
Adjustable 0.05–5 Second Delay
Timing is set by an onboard potentiometer and spans a single range from 0.05 sec to 5 sec. This fixed window determines whether the relay matches a given sequence; applications needing shorter pulses, longer delays or multiple timing functions will require a different device.
Highlights
- Adjustable timing from 0.05 to 5 seconds with potentiometer control
- DPDT contacts switch 10 A at 240 V AC or 30 V DC
- 12 V DC coil voltage suits low-voltage control circuits
- Octal 8-pin plug-in base enables quick socket mounting
- IP20 enclosed housing protects internal components
Specifications
| Brand | DAYTON |
|---|
Questions about this item
How is the 12V DC octal relay installed, and which step do people often get wrong?
Plug the 8-pin octal base into a compatible socket; the step often missed is confirming the socket supplies 12V DC to the coil before applying power.
What maintenance or replacement will the DPDT contacts need later?
The enclosed IP20 contacts are rated 10A at 240V AC or 30V DC; replace the relay once contact resistance rises or the 10A rating can no longer be met.
What limit appears first during sustained on-delay operation?
The potentiometer adjustment tops out at 5 seconds, so any timing requirement beyond 5 seconds cannot be met with this relay.
