Dayton 24EN76 Time Delay Relay Octal Interval 240V AC DPDT 10A 0.1-10s 8-Pin Plug-In
Octal plug-in interval relay with 0.1-10 s adjustable delay, 240 V AC coil, DPDT 10 A contacts
- Adjustable 0.1–10 s interval timing for precise control
- 10 A DPDT contacts switch AC or DC loads reliably
- 240 V AC coil voltage matches common industrial supplies
- Octal 8-pin plug-in base enables quick socket mounting
- IP20 enclosed housing protects internal components
Dayton 24EN76 Time Delay Relay
The Dayton 24EN76 is a single-function interval-on time delay relay rated for 240V AC coil voltage. It provides a DPDT contact form with a 10 A rating at 240V AC and 10 A at 30V DC for switching loads in control circuits.
Octal 8-Pin Plug-In Installation
The relay mounts via an octal 8-pin plug-in base for quick socket connection without soldering. Adjustment uses a potentiometer to set the delay between .1 and 10 seconds. Ensure the socket is rated for the load current and that wiring matches the DPDT pinout to avoid misoperation.
Suited for Interval Timing in Panels
This unit suits panels needing a single interval-on delay with 240V AC control voltage. It is not for applications requiring multiple delay functions, on-delay or off-delay modes, or coil voltages other than 240V AC. Builders needing programmable multi-function timers should look elsewhere.
Highlights
- Adjustable 0.1–10 s interval timing for precise control
- 10 A DPDT contacts switch AC or DC loads reliably
- 240 V AC coil voltage matches common industrial supplies
- Octal 8-pin plug-in base enables quick socket mounting
- IP20 enclosed housing protects internal components
Specifications
| Brand | DAYTON |
|---|
Questions about this item
How do I confirm the relay is timing correctly after wiring it?
Apply 240V AC to the coil, then measure the DPDT contacts with a multimeter; they should switch after the potentiometer-set interval between .1 and 10 seconds.
What comes in the box and what must I source separately?
The relay itself is supplied; you must provide an 8-pin octal socket and the 240V AC control supply.
Which timing range version should I select for my application?
This model covers a single interval-on range of .1 to 10 seconds; choose it when your required delay falls within those limits.
