Dayton 24EN69 Time Delay Relay, Octal, Interval, 24V AC/DC
Interval-on time delay relay with octal plug-in base, 0.1–10 s range and DPDT contacts rated 10 A at 240 V AC or 30 V DC
- Interval timing from 0.1 to 10 seconds covers short-cycle needs
- DPDT contacts switch 10 A at 240 V AC or 30 V DC
- 24 V AC/DC coil works with common control voltages
- Octal 8-pin plug-in base enables quick socket mounting
- IP20 enclosed housing protects internal components
Single-Function Interval Relay
The Dayton 24EN69 is a single-function time-delay relay designed for interval-on timing in control circuits. It plugs into an octal socket and provides one adjustable delay function for automated equipment.
Verify Coil Voltage and Contact Ratings
Confirm your control circuit supplies 24 V AC or DC to match the relay coil. The DPDT contacts are rated for 10 A at 240 V AC and 10 A at 30 V DC, so the load must stay within those limits. The IP20 enclosure requires a protected mounting location.
Suits Simple Interval Timing Needs
This unit suits panels that need a single interval-on delay adjustable between 0.1 and 10 seconds. It is not for applications requiring multiple timing modes, longer delay ranges or higher contact currents.
Highlights
- Interval timing from 0.1 to 10 seconds covers short-cycle needs
- DPDT contacts switch 10 A at 240 V AC or 30 V DC
- 24 V AC/DC coil works with common control voltages
- Octal 8-pin plug-in base enables quick socket mounting
- IP20 enclosed housing protects internal components
Specifications
| Brand | DAYTON |
|---|
Questions about this item
Does the 24EN69 relay ship with a socket or must I buy an 8-pin octal base separately?
The relay uses an 8-pin octal plug-in connection; a compatible socket is not included and must be purchased separately.
Which delay range should I select if my process needs anything from a tenth of a second up to ten seconds?
The single interval-on function adjusts continuously from .1 sec to 10 sec via the built-in potentiometer, covering the whole range in one model.
What does the 10 A @ 240 V AC rating mean when the relay is controlling a motor starter coil?
The DPDT contacts are rated to switch 10 A at 240 V AC, so the relay can directly drive typical starter coils within that limit.
