Dayton 24EN67 Time Delay Relay Octal Interval 12V DC DPDT 10A
Interval time-delay relay with octal plug-in base, 12 V DC coil, DPDT contacts rated 10 A at 240 V AC or 30 V DC, adjustable from 1.8 seconds to 3 minutes
- Adjustable timing from 1.8 seconds up to 3 minutes
- 12 V DC coil voltage for low-voltage control circuits
- DPDT contacts rated 10 A at 240 V AC or 30 V DC
- Octal 8-pin plug-in base for quick socket mounting
- Enclosed IP20 housing protects internal components
Single-Function Interval Relay
The Dayton 24EN67 is a single-function time delay relay designed for interval-on timing in control circuits. It operates on a 12V DC coil and switches loads through DPDT contacts rated at 10 A for both 240V AC and 30V DC. The unit plugs into an octal socket for straightforward panel installation.
Suits Automated Timing Tasks
This relay suits applications needing a single adjustable interval between 1.8 seconds and 3 minutes, such as motor starters, process timers or lighting sequences. The potentiometer adjustment allows on-site changes without tools. It is not for circuits requiring multiple delay functions, cyclic operation or timing ranges outside the stated window.
12V DC Coil Voltage Is Mandatory
The coil requires a 12V DC supply; applying any other voltage will prevent correct operation or damage the relay. Verify the control circuit provides exactly 12V DC before wiring. The octal pin layout and IP20 enclosure complete the critical installation constraints.
Highlights
- Adjustable timing from 1.8 seconds up to 3 minutes
- 12 V DC coil voltage for low-voltage control circuits
- DPDT contacts rated 10 A at 240 V AC or 30 V DC
- Octal 8-pin plug-in base for quick socket mounting
- Enclosed IP20 housing protects internal components
Specifications
| Brand | DAYTON |
|---|
Questions about this item
How much heat does the 12 V DC coil generate during continuous operation?
The coil draws 12 V DC and the relay is rated IP20, so normal warmth is expected; ensure the socket has free airflow to keep temperatures stable.
What socket and wiring must I already have to install the octal plug-in relay?
You need an 8-pin octal socket with flat-pin contacts and wiring rated for 10 A at 240 V AC or 30 V DC to match the DPDT contacts.
Will the 1.8 s to 3 min interval timer work with legacy 12 V control panels?
Yes, the 12 V DC input and adjustable 1.8 s–3 min interval function are compatible with older 12 V panels that can supply the coil voltage.
