Wall-mounted push-button station with three round operators labeled Raise, Lower, Stop in black and red on a grey enclosure

Dayton

Dayton 20C798 Push Button Control Station Raise/Lower/Stop 25mm

SKU CH-K998-Y7MWQ

A three-button push-button station with Raise, Lower and Stop legends, 25 mm operators and a 10 A contact rating at 600 V AC

  • Engine BrandDAYTON
  • Engine Size25 mm
  • Three momentary push buttons for raise lower stop control
  • 25 mm operator size fits standard industrial panel cutouts
  • NEMA 1 IP40 enclosure protects contacts in indoor environments
  • 10 A at 600 V AC and 5 A at 24 V DC contact rating handles motor starter circuits
  • Wall mount with 1/2 to 3/4 in NPT hub simplifies conduit entry

Three-button control station

The Dayton 20C798 is a wall-mounted push-button station with three momentary operators labelled Raise, Lower and Stop. It is intended for industrial machinery control where simple up, down and emergency-stop functions are required.

25 mm operators with 10 A AC rating

Each 25 mm plastic head provides momentary action; the contact block is rated 10 A at 600 V AC and 5 A at 24 V DC with a 2NO/3NC configuration. The NEMA 1 enclosure and IP40 rating limit use to dry indoor environments.

Momentary action and NEMA 1 enclosure

All three buttons are momentary with no mechanical interlock, so the station suits manual jog or positioning tasks rather than maintained-run applications. The plastic head and NEMA 1 rating mean the unit is not suited for wet, dusty or outdoor locations.

Highlights

  • Three momentary push buttons for raise lower stop control
  • 25 mm operator size fits standard industrial panel cutouts
  • NEMA 1 IP40 enclosure protects contacts in indoor environments
  • 10 A at 600 V AC and 5 A at 24 V DC contact rating handles motor starter circuits
  • Wall mount with 1/2 to 3/4 in NPT hub simplifies conduit entry

Specifications

Engine BrandDAYTON
Engine Size25 mm

Questions about this item

Will the 25 mm push buttons line up with the cutouts on my existing 1/2 in to 3/4 in NPT conduit hubs?

Yes — the station mounts on a wall and accepts 1/2 in to 3/4 in NPT hubs, so the 25 mm operators align with standard conduit entries.

How can I verify the three momentary buttons are wired correctly after installation?

Press each button and confirm the corresponding circuit changes state — Raise and Lower use 2NO contacts, Stop uses 3NC contacts, all rated 10 A at 600 V AC.

Does the box include the contact blocks and legend plates, or must I order them separately?

The station ships complete with three momentary push-button operators, black and red caps, Raise/Lower/Stop legends, and the 2NO/3NC contact blocks factory-wired.
