Dayton 24 inch industrial ceiling fan steel finish non oscillating

Dayton

Dayton 1VCG4 Industrial Ceiling Fan 24" 277V 6050 CFM

SKU CH-E14E-6JZVF

A 24-inch stationary industrial ceiling fan delivering 6050 CFM at 277 VAC with a 1/2 hp motor

  • styleNon-oscillating
  • typeIndustrial
  • High airflow of 6050 CFM for large industrial spaces
  • Direct-drive 1/2 hp motor runs at 1100 RPM with no belts to maintain
  • Operates on 277 V single-phase power common in commercial buildings
  • Quiet 73 dBA sound level suits occupied work areas
  • Withstands ambient temperatures up to 104 °F for harsh environments

Industrial Air Circulation

The Dayton 1VCG4 is a stationary industrial ceiling fan built for warehouses, workshops and large commercial spaces that need steady, high-volume airflow. Its 24-inch blade diameter and 6050 CFM rating suit environments where consistent air movement matters more than oscillation.

Steel Construction and Fixed Mounting

A steel frame houses a 1/2 hp permanent split capacitor motor running at 1100 RPM on 277 VAC single-phase power. The fan head mounts directly without a downrod, drawing 1.8 amps and 450 watts while producing 73 dBA at a maximum ambient temperature of 104 degrees F.

Electrical and Clearance Check

Verify that the supply is 277 VAC 60 Hz single-phase and that the circuit can handle the rated current. Confirm the ceiling structure can support the 27-inch width, 31-inch height and 24-1/4-inch depth envelope with the required clearances for a stationary fan head.

Highlights

  • High airflow of 6050 CFM for large industrial spaces
  • Direct-drive 1/2 hp motor runs at 1100 RPM with no belts to maintain
  • Operates on 277 V single-phase power common in commercial buildings
  • Quiet 73 dBA sound level suits occupied work areas
  • Withstands ambient temperatures up to 104 °F for harsh environments

Specifications

BrandDayton
styleNon-oscillating
typeIndustrial

Questions about this item

Does the 277 V AC supply limit the motor to a single 1100 RPM speed?

Yes, the permanent-split-capacitor motor runs at one fixed speed of 1100 RPM on 277 V AC, 60 Hz, drawing 1.8 amps and 450 watts.

What physical clearance does the 27-inch diameter head need for a head-only mount?

The unit measures 27 inches wide, 31 inches high and 24-1/4 inches deep, so allow at least that much clear space around the mounting point.

How is the fan head secured, and what step is often missed?

The head bolts directly to a structural ceiling mount; the step often missed is verifying the structure can carry the motor weight and vibration at 1100 RPM.
