Dayton 30-inch oscillating industrial ceiling fan in steel finish

Dayton

Dayton 1VCF4 Standard-Duty Industrial Ceiling Fan 30" Oscillating 115VAC

SKU CH-67JC-NK6VW

Oscillating 30-inch industrial ceiling fan delivers 9800 CFM on high and 8800 CFM on low from a 1/2 hp direct-drive motor at 115V AC

  • styleOscillating
  • typeIndustrial
  • Oscillating motion spreads air across a wide area
  • 9,800 CFM high speed moves large volumes quickly
  • 1/2 hp motor delivers 1,100 RPM on high setting
  • Direct-drive design reduces maintenance with fewer moving parts
  • 75 dBA sound level suits industrial environments

Standard-Duty Industrial Air Circulator

The Dayton 1VCF4 is a 30-inch oscillating ceiling fan built for industrial environments requiring broad air movement. It operates on 115V AC single-phase power with a 1/2 hp permanent split capacitor motor. Two-speed settings deliver 9800 CFM on high and 8800 CFM on low. The unit mounts via the fan head only.

Sustained Airflow Performance

At high speed the motor runs at 1100 RPM drawing 4.2 amps and 450 watts; low speed drops to 850 RPM, 3.3 amps and 370 watts. Air velocity reaches 760 feet per minute at 20 feet on high and 710 on low. Sound output is rated at 75 dBA. The maximum ambient operating temperature is 104 degrees Fahrenheit.

Steel Construction and Mounting Implications

A steel frame measures 33 inches in outside diameter, height and width, providing a rigid structure for the direct-drive motor. The oscillating function distributes air across a wider area without manual repositioning. Because mounting is limited to the fan head, installers must ensure the supporting structure can handle the unit’s full profile and vibration during continuous 60 Hz operation.

Highlights

  • Oscillating motion spreads air across a wide area
  • 9,800 CFM high speed moves large volumes quickly
  • 1/2 hp motor delivers 1,100 RPM on high setting
  • Direct-drive design reduces maintenance with fewer moving parts
  • 75 dBA sound level suits industrial environments

Specifications

BrandDayton
styleOscillating
typeIndustrial

Questions about this item

How loud is the fan at its 75 dBA sound level when running all day?

The unit produces 75 dBA, which is comparable to a busy office or light traffic, and draws 4.2 amps at high speed or 3.3 amps at low speed on a 115 VAC 60 Hz circuit.

What electrical supply and mounting does the fan require to operate?

It needs a standard 115 VAC single-phase 60 Hz outlet and is designed for fan-head-only mounting with no additional brackets included.

Will the 30-inch blade diameter and 9800 CFM high airflow overwhelm a smaller workshop space?

At high speed the fan moves 9800 CFM with 760 fpm velocity at 20 feet; at low speed it drops to 8800 CFM and 710 fpm, so you can reduce airflow for tighter areas.
