Dayton
Dayton 1RWB4 30" Non-Oscillating Industrial Ceiling Fan 115VAC
A 30-inch non-oscillating industrial ceiling fan delivering 7,250 CFM on high and 4,650 CFM on low at 115V AC
- styleNon-oscillating
- typeCommercial
- 30-inch blade span moves up to 7,250 CFM for large-area cooling
- Two-speed PSC motor runs at 1,100 or 900 RPM for airflow choice
- Direct-drive design eliminates belt wear and cuts maintenance
- Mounts to ceiling or wall for flexible industrial placement
- Operates up to 104 °F ambient temperature in tough environments
Industrial ceiling fan for commercial spaces
The Dayton 1RWB4 is a light-duty industrial ceiling fan built for warehouses, workshops and large retail areas that need steady air movement. Its 30-inch blade diameter and direct-drive motor deliver high-volume airflow without oscillation, making it suited for fixed-position cooling or ventilation tasks.
Ceiling or wall mounting with two-speed control
Installation uses standard ceiling or wall mounting hardware and a 115 VAC single-phase supply; the permanent split capacitor motor runs at two fixed speeds selected by a compatible switch. The non-oscillating design eliminates moving pivot parts, so there are fewer mechanical points that can wear or loosen over time.
7250 CFM at high speed decides coverage
At the high 1100 RPM setting the fan moves 7250 CFM with an air velocity of 715 feet per minute at 20 feet, while the low 900 RPM setting provides 4650 CFM. If the space requires airflow above or below this range, a different blade diameter or motor rating will be necessary.
Highlights
- 30-inch blade span moves up to 7,250 CFM for large-area cooling
- Two-speed PSC motor runs at 1,100 or 900 RPM for airflow choice
- Direct-drive design eliminates belt wear and cuts maintenance
- Mounts to ceiling or wall for flexible industrial placement
- Operates up to 104 °F ambient temperature in tough environments
Specifications
| Brand | Dayton |
|---|---|
| style | Non-oscillating |
| type | Commercial |
Questions about this item
How do I confirm the fan is moving the rated 7250 CFM on high speed after installation?
Measure airflow at 20 ft with an anemometer; you should read approximately 715 fpm on high and 480 fpm on low.
What mounting hardware is included and what must I supply for ceiling or wall installation?
The fan ships as a complete 30 in blade unit with direct-drive motor; mounting brackets and electrical connectors for 115 VAC supply are not included.
The specs list both 115 VAC and 120 VAC — which voltage version should I order?
The single model operates on standard 120 V, 60 Hz circuits and draws 2.9 A on high, 1.9 A on low.
