Transparent octal plug-in relay with potentiometer adjustment

Dayton

Dayton 1EGC1 Time Delay Relay 120V 10A On Delay

SKU CH-9HAM-7YZ5P

Provides adjustable on-delay timing from 3 seconds to 5 minutes with a 10 A DPDT contact for 120 V AC/DC control circuits

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • On-delay timing up to 5 minutes adjustable via potentiometer
  • DPDT contacts rated 10 A at 240 V AC and 30 V DC
  • 120 V AC/DC coil voltage for direct mains control
  • Octal 8-pin plug-in base for quick socket mounting
  • IP20 enclosed housing protects internal components

Single-function time delay relay

The Dayton 1EGC1 is a single-function time delay relay designed for industrial control panels and automation circuits that require a simple on-delay action. It suits electricians and panel builders who need a plug-in device with a transparent enclosure for visual inspection.

Plug-in octal base installation

The unit mounts on a standard octal socket using eight flat pins, so wiring is completed at the socket rather than on the relay itself. The potentiometer adjustment is accessible on the face, but the sealed IP20 enclosure prevents internal tampering and limits use to protected indoor cabinets.

Adjustable 3-second to 5-minute delay

The on-delay timer spans from 3 seconds up to 5 minutes, covering typical motor-start sequencing and staggered load energising. The DPDT contacts switch 10 amps at 240 volts AC or 30 volts DC, so the relay cannot handle higher currents or voltages without an external contactor.

Highlights

  • On-delay timing up to 5 minutes adjustable via potentiometer
  • DPDT contacts rated 10 A at 240 V AC and 30 V DC
  • 120 V AC/DC coil voltage for direct mains control
  • Octal 8-pin plug-in base for quick socket mounting
  • IP20 enclosed housing protects internal components

Specifications

BrandDAYTON
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

How can I verify the relay is timing correctly after installation?

Apply 120 V AC/DC to the coil and confirm the DPDT contacts switch after the potentiometer-set interval between 3 sec and 5 min.

What comes in the box and what must I supply separately?

The relay itself is supplied; you must provide an octal 8-pin socket and wiring for the 120 V coil and 10 A load circuits.

Which time-delay version should I choose for a simple power-on delay?

This model provides a single On Delay function adjustable from 3 sec to 5 min, matching that requirement.
