Transparent relay housing with four quick connect tabs and LED indicator

Dayton

Dayton 15V826 Adjustable Current Sensor Relay 10A 24VAC 4-Pin

SKU CH-4FXK-KH9PY

Monitors AC or DC current with an adjustable 5 to 50 A trip point and SPDT 10 A contacts

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Adjustable 5–50 A trip point prevents overloads
  • SPDT contacts switch 10 A at 240 V AC
  • LED status indicator shows relay state instantly
  • Quick-connect tabs enable fast 4-pin wiring
  • Compact 3.5 × 2.5 × .8 in body fits tight panels

Product Identity

The Dayton 15V826 is an adjustable current sensing relay designed for industrial electrical control and automation panels. It monitors AC circuits for overcurrent and undercurrent conditions using a solid core with a 0.36 in sensing hole diameter. The relay operates on 24V AC input and provides a SPDT contact rated at 10 A @ 240V AC or 8 A @ 28V DC. An LED status indicator shows trip status at a glance.

Installation Notes

The unit mounts on a flat surface using its 2.5 in by 3.5 in body footprint and 0.8 in depth. Four quick connect tabs accept standard push on terminals for fast wiring without tools. The trip point adjusts from 5 to 50 A via an accessible dial; verify the setting with a calibrated load before commissioning. Common issues include loose quick connect tabs causing intermittent contact and incorrect trip point selection for the actual load current.

Pre Order Checks

Confirm the control circuit supplies 24V AC and that the monitored conductor fits through the 0.36 in sensing hole. Ensure the load current falls within the 5 to 50 A adjustable range and does not exceed the 10 A contact rating at 240V AC or 8 A at 28V DC. Verify the panel has sufficient clearance for the 2.5 in width 3.5 in height 0.8 in depth body and that a SPDT switching action matches the control logic required.

Highlights

  • Adjustable 5–50 A trip point prevents overloads
  • SPDT contacts switch 10 A at 240 V AC
  • LED status indicator shows relay state instantly
  • Quick-connect tabs enable fast 4-pin wiring
  • Compact 3.5 × 2.5 × .8 in body fits tight panels

Specifications

BrandDAYTON
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

How can I verify the relay is operating correctly after wiring it?

The built-in LED indicator lights when the relay trips, confirming the adjustable set-point between 5 and 50 A has been reached.

What comes in the package and what must I source separately?

The unit itself is supplied; quick-connect tabs are integrated, so only mating connectors and mounting hardware need to be provided by the installer.

Which trip-point range suits a 10 A load on a 24 V AC circuit?

The adjustable 5 to 50 A range covers the 10 A contact rating, allowing the set-point to be tuned precisely for the monitored conductor.
