White metal wall-mounted oscillating fan with 18 inch blades and protective grille

Dayton

Dayton 13V401 Wall Mount Oscillating Fan 18 in 120V

SKU CH-WGJT-WMR5W

Wall-mounted oscillating fan with 18-inch blades delivers 5700 CFM on high and 4000 CFM on low at 120V

  • styleOscillating
  • typeCommercial
  • Oscillating wall fan covers wider area with 18 in blade diameter
  • Two-speed motor delivers up to 5700 CFM on high for strong airflow
  • Permanent split capacitor motor runs at 70 dBA for quieter operation
  • Direct-drive design with 1/7 hp motor provides reliable performance
  • Mounts on wall at 37 in height and 24 in max depth

Wall-Mount Oscillating Fan 18 in

The Dayton 13V401 is a commercial-grade wall-mounted fan with an 18-inch blade diameter. It operates on 120V AC single-phase power at 60 Hz. The unit provides two-speed oscillation for air circulation in industrial or commercial spaces.

Direct-Drive Motor 1/7 HP

A permanent split capacitor motor drives the blades directly without belts. The fan mounts to a wall, projecting up to 24 inches into the room. It draws 2.0 amps on high and 1.5 amps on low, consuming 220 watts and 175 watts respectively.

Sustained Airflow 5700 CFM High

At high speed the fan moves 5700 CFM at 1100 RPM, producing 415 fpm air velocity at 20 feet. Sound level reaches 70 dBA during continuous operation. The motor is rated for ambient temperatures up to 104 degrees F.

Highlights

  • Oscillating wall fan covers wider area with 18 in blade diameter
  • Two-speed motor delivers up to 5700 CFM on high for strong airflow
  • Permanent split capacitor motor runs at 70 dBA for quieter operation
  • Direct-drive design with 1/7 hp motor provides reliable performance
  • Mounts on wall at 37 in height and 24 in max depth

Specifications

BrandDayton
styleOscillating
typeCommercial

Questions about this item

Will the 1/7 hp motor overheat if I run the fan continuously at high speed?

The motor is rated for a maximum ambient temperature of 104 degrees F and draws 2.0 amps at high speed, so sustained operation within that temperature range is supported.

How loud is the 70 dBA sound level when the fan runs all day in a workshop?

At 70 dBA the fan produces a noticeable but moderate hum comparable to a busy office, which remains consistent at both 1100 RPM and 925 RPM settings.

Does the wall-mount bracket come in the box or do I need to buy separate mounting hardware?

The fan includes a standard wall-mount accessory style, so the necessary bracket and hardware are supplied for direct installation.
