Compact white fixed-mount 2D barcode scanner with USB cable, 1.5 by 2.2 by 2.3 inches

Datalogic

Datalogic Gryphon GFS4470 2D Barcode Scanner USB

SKU CH-91K6-JDQNH MPN GFS4470

Fixed-mount 2D imager reads 1D, 2D and postal codes via USB with omnidirectional scanning and a 4-dot aimer for kiosk integration

  • Interfaces SupportedUSB
  • Light Source650 nm visible laser diode
  • Pitch±40 degree
  • Roll±180 degree
  • Yaw±40 degree
  • Decoding Capability1D / Linear Codes: Autodiscriminates all standard 1D codes i
  • Omnidirectional scanning captures codes from any angle
  • 4-Dot aimer with centre-cross speeds up targeted reads
  • Advanced motion tolerance keeps decoding reliable on moving items
  • Reads 1D, 2D and postal symbologies including QR and Data Matrix
  • Compact 1.5 x 2.2 x 2.3 in sealed body fits tight OEM spaces

Fixed-mount 2D imager for OEM integration

The Datalogic Gryphon GFS4470 is a fixed-mount barcode scanner built for embedding into self-service kiosks, price verifiers, ticket readers, document handling systems, medical laboratory equipment, vending machines and other automated devices. It connects through a USB interface and uses a 650 nm visible laser aimer with a 4-dot centre-cross for targeted scanning. The sealed enclosure is constructed from high-impact resin designed to withstand repeated cleaning with solvents and disinfectants.

Suited for system designers needing plug-and-play

This unit suits engineers designing automated equipment that requires omnidirectional reading of 1D, 2D, postal and stacked symbologies including QR Code, Data Matrix, Aztec, MaxiCode, GS1 DataBar composites and major postal codes. Advanced motion tolerance optics allow reliable capture of codes down to 4 mils. It is not for operators needing a handheld trigger device, wireless freedom, or alternative host interfaces.

USB interface decides integration path

The sole supported host interface is USB, which determines whether the scanner can be integrated into the target system without additional conversion hardware. Physical dimensions are 1.5 x 2.2 x 2.3 in and weight is 6.3 oz, factors that constrain the mounting space available inside the host device.

Highlights

  • Omnidirectional scanning captures codes from any angle
  • 4-Dot aimer with centre-cross speeds up targeted reads
  • Advanced motion tolerance keeps decoding reliable on moving items
  • Reads 1D, 2D and postal symbologies including QR and Data Matrix
  • Compact 1.5 x 2.2 x 2.3 in sealed body fits tight OEM spaces

Specifications

BrandDatalogic
SeriesGRYPHON
Part NumberGFS4470
Interfaces SupportedUSB
Light Source650 nm visible laser diode
Pitch±40 degree
Roll±180 degree
Yaw±40 degree
Decoding Capability1D / Linear Codes: Autodiscriminates all standard 1D codes including GS1 DataBar linear codes
2D Codes:
- Aztec Code
- China Han Xin Code
- Data Matrix
- MaxiCode
- Micro QR Code
- QR Code
Postal Codes:
- Australian Post
- British Post
- China Post
- IMB
- Japanese Post
- KIX Post
- Korea Post
- Planet Code
- Postnet
- Royal Mail Code (RM4SCC)
Stacked Codes:
- EAN/JAN Composites
- GS1 DataBar Composites
- GS1 DataBar Expanded Stacked
- GS1 DataBar Stacked
- GS1 DataBar Stacked Omnidirectional
- MacroPDF
- MicroPDF417
- PDF417
- UPC A/E Composites
Dimensions1.5 x 2.2 x 2.3 in
Weight6.3 oz.
FeaturesHighly visible 4-Dot aimer with center-cross for targeted scanning
Omnidirectional reading
Advanced motion tolerance optics
Image capture and document scanning capabilities
Reads bar codes down to 4mils
Reads 1D, 2D and postal codes plus stacked and composite codes
Datalogic's Green Spot for good-read feedback
Integrated good-read beeper
High-impact resin creates a solvent-tolerant enclosure
Water and Particulate Sealing Rating: IP54
Shipping weight0.20 kg
Package size112 × 109 × 89 mm

Questions about this item

Which Datalogic Gryphon GFS4470 variant should I choose for USB connectivity?

The GFS4470 is supplied with USB as the only supported host interface, so no other variant or capacity option exists for this model.

What does the 650 nm visible laser diode mean for everyday scanning?

The 650 nm laser provides a highly visible 4-Dot aimer with centre-cross, enabling targeted omnidirectional reading and advanced motion tolerance in real use.

How does the USB interface limit data throughput on this fixed scanner?

USB delivers a plug-and-play connection for OEM integration; the scanner autodiscriminates all standard 1D, GS1 DataBar, 2D and postal symbologies within that link.
