Compact white desktop switch with eight RJ45 ports and external power supply

D-Link

D-Link DGS-1100-08P 8-Port Gigabit PoE network switch

SKU CH-H6JV-5X7H2 MPN DGS-1100-08P

Eight-port Gigabit PoE switch with smart management, VLAN and QoS for small networks

  • StandardsIEEE 802.3/3u/3ab, IEEE 802.3af
  • Network Management TypeSmart
  • Primary Ports8 x RJ45
  • Primary Port Speed10/100/1000Mbps
  • MAC Address Table8K
  • Switching MethodStore and Forward
  • 8 Gigabit PoE ports power IP cameras and access points directly
  • Smart managed features include VLAN, QoS and IGMP snooping for traffic control
  • 8K MAC table and store-and-forward switching keep data moving
  • Compact desktop enclosure fits tight spaces with external power supply
  • Lifetime limited warranty backs the hardware for long-term use

8-Port Gigabit PoE Switch for Small Networks

The D-Link DGS-1100-08P provides eight RJ45 ports with 10/100/1000Mbps speed and IEEE 802.3af Power over Ethernet. It fits small offices or surveillance setups needing to power cameras or access points through the network cable. Smart management features include VLAN, QoS and link aggregation for traffic control.

Suits Installers Needing PoE and Basic Management

This switch serves builders who want a compact desktop unit with 8K MAC address table and store-and-forward switching. It is not for buyers who need Layer 3 routing, fibre uplinks or a higher PoE power budget per port. Operations requiring command-line configuration or stacking should look at fully managed alternatives.

802.3af PoE Standard Defines Power Delivery

Each port follows the IEEE 802.3af standard for powered devices. The external universal power supply accepts 100 to 240 VAC at 50 to 60 Hz. Confirm that your endpoints comply with this PoE class before deployment. The compact enclosure measures 7.4" x 4.7" x 1.1" and weighs 1.6lbs.

Highlights

  • 8 Gigabit PoE ports power IP cameras and access points directly
  • Smart managed features include VLAN, QoS and IGMP snooping for traffic control
  • 8K MAC table and store-and-forward switching keep data moving
  • Compact desktop enclosure fits tight spaces with external power supply
  • Lifetime limited warranty backs the hardware for long-term use

Specifications

BrandD-Link
ModelDGS-1100-08P
StandardsIEEE 802.3/3u/3ab, IEEE 802.3af
Network Management TypeSmart
Primary Ports8 x RJ45
Primary Port Speed10/100/1000Mbps
MAC Address Table8K
Switching MethodStore and Forward
VLAN SupportYes
Buffer Memory2Mbits Packet
ProtocolsTCP/IP
SecurityStatic MAC Address
Broadcast/Multicast/Unknown Unicast Storm Control
PoEYes
QoSYes
Layer2
Port MirroringYes
LEDsPower (Per Device)
Link/Activity/Speed (Per Port)
PoE Max.
Power100 to 240 VAC, 50 to 60 Hz
External Universal Power Supply
Dimensions7.4" x 4.7" x 1.1"
Weight1.6lbs.
Temperature0°C to 50°C (32°F to 122°F)
Humidity10% - 95%, Non-condensing
FeaturesSwitching Capacity: 16Gbps
Max. Forwarding Rate: 11.9 Mpps
PoE:
PoE Standard: 802.3af
PoE Capable Ports: Ports 1-8
PoE Power Budget: 64W
D-Link Green
Shipping weight1.09 kg
Package size216 × 185 × 76 mm

Questions about this item

What does the IEEE 802.3af standard mean for power delivery on the 8 Gigabit RJ45 ports?

The 802.3af standard provides Power over Ethernet on all eight Gigabit RJ45 ports for devices such as IP cameras or access points.

What are the physical dimensions and weight of the DGS-1100-08P desktop enclosure?

The compact desktop enclosure measures 7.4 inches by 4.7 inches by 1.1 inches and weighs 1.6 lbs.

How is the switch powered and what voltage range does the external supply accept?

An external universal power supply connects to the unit and accepts 100 to 240 VAC at 50 to 60 Hz.
