Silver rack-mount switch with 24 RJ45 ports and two SFP slots

D-Link

D-Link DES-1210-28 WebSmart network switch 24-port 10/100 2 SFP

SKU CH-7K3F-HG6PE MPN DES-1210-28

A 24-port 10/100 Fast Ethernet switch with two Gigabit SFP uplinks, 8K MAC table and Layer 2 smart management

  • FormatRackmount
  • StandardsIEEE 802.3 10BASE-T Ethernet (twisted-pair copper) IEEE 802.
  • Network Management TypeSmart
  • Primary Ports26 x RJ45 + 2 x SFP
  • Primary Port Speed10/100Mbps + 1000Mbps
  • MAC Address Table8K
  • 24 Fast Ethernet ports connect workstations and printers
  • 2 SFP uplinks extend the network over fibre
  • Smart management enables VLANs QoS and SNMP monitoring
  • 8K MAC table supports growing device counts
  • 6 W maximum draw keeps running costs low

24-port Fast Ethernet with SFP uplinks

The D-Link DES-1210-28 is a WebSmart Layer 2 switch built for small-business networks that need managed features without full CLI complexity. Twenty-four RJ45 ports run at 10/100 Mbps while two SFP slots add Gigabit fibre uplinks, all in a rackmount chassis with an internal 100-240 VAC power supply.

Best for cost-sensitive managed access

Suits offices that need VLAN segmentation, QoS prioritisation and 802.1X port security across many endpoints on a tight budget. Not for teams that require 10/100/1000 Mbps on every copper port or Layer 3 routing between subnets.

26 total ports with 1000 Mbps SFP

The primary specification is the port mix: 24 Fast Ethernet RJ45 ports plus two SFP ports operating at 1000 Mbps. This combination determines whether the switch matches the cabling plan and uplink speed the installation demands.

Highlights

  • 24 Fast Ethernet ports connect workstations and printers
  • 2 SFP uplinks extend the network over fibre
  • Smart management enables VLANs QoS and SNMP monitoring
  • 8K MAC table supports growing device counts
  • 6 W maximum draw keeps running costs low

Specifications

BrandD-Link
SeriesWebSmart
ModelDES-1210-28
FormatRackmount
StandardsIEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted-pair copper)
IEEE 802.3z Gigabit Ethernet (fiber) ANSI/IEEE 802.3
Auto-negotiation
IEEE 802.3x Flow Control
Network Management TypeSmart
Primary Ports26 x RJ45 + 2 x SFP
Primary Port Speed10/100Mbps + 1000Mbps
MAC Address Table8K
Switching MethodStore and Forward
VLAN SupportYes
Buffer Memory512KB
ProtocolsTCP/IP
Security802.1X Port-based Access Control: Default 802.1X forwarding
Port Security: Supports up to 64 MAC addresses per port
Traffic Control: Broadcast / Multicast / Unicast Storm Control
Static MAC: Supports 256 Static MAC entries
D-Link Safeguard Engine: Yes
SNMPYes
QoSYes
Layer2
Port MirroringYes
LEDsPower (per device)
Link / Activity / Speed (per 10/100/1000Mbps port, per 10/100Mbps port, per SFP port)
PowerAC Input: 100 to 240 VAC 50/60 internal universal power supply
Maximum Power Consumption: 17.6W
Standby Power Consumption: 7.6W/110V, 7.9W/240V
FeaturesFanless Design: Provides Continuous, Reliable, Silent and Eco-Friendly Operation
Security Features: Access Control List, D-Link Safeguard Engine and Port Security
Intuitive Management: SmartConsole or Web-Based GUI, Built-in MIB Browser for SNMP, D-View 6.0 Module Support and Compact CLI through Telnet
Supports Auto Voice VLAN and DSCP QoS for VoIP Application
Number of Ports:
24 10/100Mbps
2 10/100/1000BASE-T
2 combo 10/100/1000BASE-T/SFP
Network Cables:
UTP Cat.5, Cat.5e (100m max)
EIA/TIA-568 100-ohm STP (100m max)
Switching Capacity: 12.8Gbps
Heat Dissipation: 60.05 BTU/hr
Emissi
Dimensions17.3" x 8.3" x 1.7"
Weight5.73 lbs.
TemperatureOperating: 32° to 104°F (0° to 40°C)
Storage: 14° to 158° F (-10° to 70° C)
HumidityOperating: 10% to 95% Non-condensing
Storage: 5% to 95% Non-condensing
Shipping weight4.08 kg
Package size556 × 216 × 94 mm

Questions about this item

Which cables and SFP modules do I need to connect 24 devices at 10/100 Mbps and two uplinks?

Use Cat5 or better RJ45 cables for the 24 10/100 Mbps ports; the two SFP slots accept any compatible 1000 Mbps fibre or copper modules you supply.

Will the two Gigabit SFP ports negotiate down to 100 Mbps if I link them to older 10/100 switches?

The SFP ports run at 1000 Mbps only; they do not step down to 10/100 Mbps, so legacy 10/100 gear must connect through the 24 RJ45 ports instead.

How do I confirm the switch is forwarding traffic correctly after racking it and powering on?

The per-port Link/Activity/Speed LEDs light solid for link and blink for traffic; the Power LED stays on, showing the internal 100–240 VAC supply is live.
