Square white outdoor intercom, five by five inches, two and a half inches deep, shown with optional weather shroud

CyberData Corporation

CyberData Corporation 011186 VoIP V3 Outdoor Intercom

SKU CH-EC8Y-D093H MPN 011186

A SIP-compatible outdoor intercom with a faster V3 processor, IP65 rating and PoE power for secure two-way access

  • TypeVoIP V3 Outdoor Intercom
  • SpecificationsEthernet I/F: 10/100 Mbps Protocol: SIP RFC 3261 Compatible
  • FeaturesFaster V3 processor Increased IP RATING to IP65 Now supports
  • Faster V3 processor enables more capabilities
  • IP65 rating protects against dust and water jets
  • PoE 802.3af or 12 to 24 VDC power options
  • SIP RFC 3261 compatible for broad system integration
  • Optional Weather Shroud adds extra environmental protection

Outdoor Intercom with IP65 Rating

The CyberData 011186 is a SIP-compatible VoIP intercom built for outdoor environments. Its IP65-rated enclosure protects internal components against dust and water ingress. The unit operates on Power over Ethernet or an external 12 to 24 VDC supply. It is suited for facility entrances requiring two-way audio and access control integration.

Sustained Operation on PoE or DC Power

The device draws up to 1000 mA with a 500 mA minimum across the supported voltage range. PoE 802.3af compliance allows power and data over a single cable connection. The faster V3 processor handles continuous SIP signalling and G.711 audio streams without thermal throttling. SRST support maintains call processing during network server outages.

Simple Mounting with Optional Shroud

The compact 5 by 5 by 2.5 inch case fits standard wall-mount installations using basic hardware. A single Ethernet drop provides both connectivity and power when PoE is available. The optional weather shroud adds extra protection for exposed locations. Ensure the network switch delivers sufficient PoE budget for reliable start-up.

Highlights

  • Faster V3 processor enables more capabilities
  • IP65 rating protects against dust and water jets
  • PoE 802.3af or 12 to 24 VDC power options
  • SIP RFC 3261 compatible for broad system integration
  • Optional Weather Shroud adds extra environmental protection

Specifications

BrandCyberData
Model011186
TypeVoIP V3 Outdoor Intercom
SpecificationsEthernet I/F: 10/100 Mbps
Protocol: SIP RFC 3261 Compatible
Power Input: PoE 802.3af compliantor +12 to +24 VDC at 1000 mA (500 mA minimum)
Payload Types: G711
Dimensions: 5" x 5" x 2.5"
FeaturesFaster V3 processor
Increased IP RATING to IP65
Now supports SRST (Survivable Remote Site Telephony)
New streamlined case design
*Optional Weather Shroud (pictured) for even greater
weather protection
PoE 802.3af enabled (Powered-over-Ethernet)
SIP compliant
Adaptive full-duplex voice operation
Network web management
Network adjustable speaker volume and microphone sensitivity
Network downloadable firmware
Doubles as a paging speaker
Dry relay contact for auxiliary control (controls external power)
Peer-to-peer capable
Door closure and tamper alert signal.
Shipping weight1.81 kg
Package size305 × 229 × 102 mm

Questions about this item

How much power does the 011186 draw when running all day on PoE?

The intercom is PoE 802.3af compliant, drawing up to 1000 mA, with a minimum of 500 mA for continuous operation.

What cabling and power source must I already have to install this intercom?

You need a 10/100 Mbps Ethernet connection and either a PoE 802.3af switch or a separate +12 to +24 VDC supply rated for at least 500 mA.

Will the IP65-rated 011186 work reliably alongside my existing SIP desk phones on the same PBX?

Yes, it uses SIP RFC 3261 and G.711 payloads, so it registers to the same PBX as standard SIP phones and supports SRST for failover.
