CUTLER-HAMMER 10250T21LB selector switch 30mm 3 position lever
30 mm three-position selector switch with lever operator, 10 A at 600 V AC and IP68 rating
- 30 mm lever operator fits standard panels
- Three maintained positions for clear mode selection
- Two normally-open contacts rated 10 A at 600 V AC
- NEMA 12, 13, 3, 3R, 4, 4X and IP68 enclosure protection
- Metal body with zinc bezel built for industrial durability
30 mm three-position selector switch
The CUTLER-HAMMER 10250T21LB is a 30 mm non-illuminated selector switch built for industrial control panels. Its lever operator provides maintained action across three distinct positions for clear mode selection.
10 A at 600 V AC contact rating
Rated at 10 A and 600 V AC with NEMA A600/P600 designation, the switch handles standard motor starter and pilot duty circuits. The 2NO contact form opens in the centre position, limiting use to applications that require both outer circuits active simultaneously.
IP68 and NEMA 4X panel mounting
A polymer operator head with zinc bezel meets NEMA 3, 3R, 4, 4X, 12 and 13 plus IP68, so the unit resists wash-down and corrosion in harsh environments. The 30 mm cut-out fits standard panel layouts without additional adapters.
Highlights
- 30 mm lever operator fits standard panels
- Three maintained positions for clear mode selection
- Two normally-open contacts rated 10 A at 600 V AC
- NEMA 12, 13, 3, 3R, 4, 4X and IP68 enclosure protection
- Metal body with zinc bezel built for industrial durability
Specifications
| Brand | EATON |
|---|
Questions about this item
Will the 30 mm lever operator fit the existing panel cutout on my 10250 series enclosure?
The 30 mm operator head is designed for standard 30 mm panel cutouts used across the 10250 range, so it matches the mounting pattern of your current enclosure.
How can I verify the three maintained positions are wired correctly after installation?
Operate the lever to each position and check continuity: Position A should show XO (first contact closed, second open), Position B OO (both open), and Position C OX (first open, second closed).
Does the package include the 2NO contact block or must I order it separately?
The selector switch ships with the 2NO contact block already assembled to the operator, so no separate contact-block purchase is required for basic operation.
