CUTLER-HAMMER
CUTLER-HAMMER 10250T1367 Selector Switch 30mm 4 Pos Knob
30 mm four-position maintained selector switch with black knob operator, metal head, anodised aluminium chrome bezel, NEMA 12, 13, 3, 3R, 4, 4X and IP65 ratings
- 30 mm mounting fits standard panels
- Four maintained positions for multi-mode control
- NEMA 12, 13, 3, 3R, 4, 4X rated for harsh environments
- IP65 sealing resists dust and water jets
- Anodized aluminium bezel with chrome finish resists corrosion
30 mm 4-position selector switch
The Cutler-Hammer 10250T1367 is a 30 mm non-illuminated selector switch designed for industrial control panels. It suits maintenance engineers and panel builders who need a maintained four-position rotary actuator for machine-start or mode-selection circuits.
Metal operator with anodised aluminium bezel
The operator head is metal with a black knob and a chrome anodised aluminium bezel, rated NEMA 12, 13, 3, 3R, 4 and 4X plus IP65. This construction resists dust, oil, water jets and corrosion, so the switch remains operable in harsh machinery environments without additional sealing.
Four maintained positions using Cam 7
Cam 7 provides four maintained detents, meaning the knob stays in each selected position until turned again. The switch carries CSA and UL listings, but it has no key removal feature and no illumination, so it cannot serve applications that require keyed security or visual status indication.
Highlights
- 30 mm mounting fits standard panels
- Four maintained positions for multi-mode control
- NEMA 12, 13, 3, 3R, 4, 4X rated for harsh environments
- IP65 sealing resists dust and water jets
- Anodized aluminium bezel with chrome finish resists corrosion
Specifications
| Brand | EATON |
|---|
Questions about this item
Which NEMA and IP ratings does the 10250T1367 selector switch meet?
The switch is rated NEMA 12, 13, 3, 3R, 4 and 4X, and it also carries an IP65 rating for dust and water protection.
What panel cut-out size and bezel material does this 30 mm switch require?
It mounts in a standard 30 mm cut-out and uses an anodised aluminium bezel with a chrome finish.
How is the 10250T1367 wired, and what common mistake should be avoided?
Wire the contacts according to cam 7 for the four maintained positions; a frequent error is assuming a spring-return action and wiring for momentary operation instead.
