COMMSCOPE SV-3BG 3-way Balanced Splitter 5-1002 MHz Red

Three-way balanced splitter

The CommScope SV-3BG divides a single coaxial feed into three equal outputs across a 5–1002 MHz bandwidth. It is built for installers and home users who need to distribute cable TV, antenna or MoCA signals to multiple rooms without favouring any port.

Horizontal-mount replacement

This unit replaces older two-way or unbalanced splitters when a third outlet is added or when equal signal levels are required on every leg. The jump is worth it when a new room is wired or when existing taps create uneven loss across the network.

5–1002 MHz headroom

The 1002 MHz upper limit comfortably handles modern DOCSIS 3.1 downstream channels and extended MoCA frequencies. It runs out when the system demands spectrum above 1 GHz or when more than three outputs are needed from a single feed.
