Red two-way coaxial splitter with horizontal mounting and two video ports

COMMSCOPE

COMMSCOPE SV-2G 2-way Coaxial Splitter 5-1002 MHz 75 ohm Red

SKU CH-S9ED-YGDV4

A 2-way coaxial splitter covering 5–1002 MHz at 75 ohm for indoor or outdoor digital cable distribution

  • ColorRed
  • Weight0.0125
  • Splits digital cable cleanly across 5–1002 MHz
  • Maintains 75 ohm impedance for stable signal quality
  • Built to ISO 9001:2008 professional standards
  • Non-ferric design prevents passive intermodulation interference
  • Lightweight at 0.0125 kg for easy indoor or outdoor mounting

Two-way splitter for digital cable

The CommScope SV-2G divides one coaxial feed into two outputs for indoor or outdoor digital cable installations. It operates across a 5–1002 MHz bandwidth at 75 ohm impedance. The red housing identifies the model in structured wiring panels. Professional-grade construction targets installers who need reliable signal distribution.

Horizontal mount with two F-type ports

The splitter mounts horizontally and presents two video ports for straightforward coaxial connections. Non-ferric materials and controlled soldering reduce passive intermodulation from corrosion or oxidation. ISO 9001:2008 manufacturing controls support consistent contact pressure. No special tools are required beyond standard coaxial compression or crimp fittings.

Handles two drops within 5–1002 MHz

Each output carries the full 5–1002 MHz spectrum for digital cable and broadband data. The two-port design suits single-split scenarios such as a modem and a set-top box. Adding further splits would require additional splitters and introduces extra insertion loss. The unit is not designed for satellite IF bands above 1002 MHz.

Highlights

  • Splits digital cable cleanly across 5–1002 MHz
  • Maintains 75 ohm impedance for stable signal quality
  • Built to ISO 9001:2008 professional standards
  • Non-ferric design prevents passive intermodulation interference
  • Lightweight at 0.0125 kg for easy indoor or outdoor mounting

Specifications

BrandCommscope
ModelSV-2G
Part NumberSV-2G
ColorRed
Weight0.0125

Questions about this item

How can I verify the splitter is passing the full 5–1002 MHz range after installation?

Connect a signal meter to each output port and confirm the insertion loss matches the 75 ohm specification across the 5–1002 MHz band.

What comes in the box and do I need to buy F-type cables separately?

The package contains the red two-way splitter with two video ports; coaxial cables with F-type connectors must be purchased separately.

Which version should I choose for a digital cable system that runs both indoors and outdoors?

The SV-2G model covers 5–1002 MHz, is rated for indoor and outdoor mounting, and meets ISO 9001:2008 quality standards.
