Cleveland Golf C65251 pneumatic accessory

Threading die for UNF 3/4-16 threads

The Cleveland Golf C65251 is a round adjustable die made from carbon steel. It cuts right-hand unified fine threads at 3/4 inch diameter with 16 threads per inch. The tool suits maintenance technicians and machinists who need to create or repair external threads on bolts, rods or pipe nipples in workshop or field service settings.

Adjustable design allows fit calibration

The die features an adjustable split construction so the thread diameter can be widened or narrowed slightly before locking. This lets the operator compensate for material spring-back or wear and achieve a precise class of fit without purchasing multiple fixed-size dies. The bright machined finish is uncoated, so cutting fluid should be applied to reduce friction and extend tool life.

Verify thread specification and holder compatibility

Before ordering, confirm the workpiece requires a 3/4-16 UNF thread form and that the die holder or stock accepts a 1 1/2 inch outside diameter with 1/2 inch thickness. The die cuts right-hand threads only; left-hand applications need a different tool. Carbon steel construction is suited to mild steel and non-ferrous metals but not to hardened alloys or high-volume production runs.
