Citizen
Citizen CL-S700II Industrial Barcode Printer 203 dpi 10 ips
Industrial thermal-transfer and direct-thermal barcode label printer printing at 10 ips with 203 dpi resolution, USB 2.0, serial and Ethernet connectivity, and 16 MB flash memory
- Print TechnologyDirect Thermal/Thermal Transfer Printer
- Printer TypeIndustrial
- Print Speed10 ips
- Max Resolution(B&W)203 dpi
- Memory16MB Flash
- Fast 10 ips throughput keeps production lines moving
- 203 dpi resolution delivers sharp, scannable barcodes
- Dual thermal modes handle direct thermal and transfer media
- USB 2.0, Serial and Ethernet ports simplify network integration
- 16 MB flash stores fonts and formats for quick job changes
Industrial Barcode Printer for High-Volume Labelling
The Citizen CL-S700II is an industrial-grade thermal transfer and direct thermal printer built for demanding labelling environments. It prints at 10 inches per second with a 203 dpi resolution. The unit supports a maximum label width of 4.65 inches and includes 16MB of flash memory. Connectivity options cover USB 2.0, serial and Ethernet for network integration.
Upgrade from Desktop or Slower Industrial Units
This model replaces desktop printers that cannot sustain continuous high-volume output or older industrial units limited to lower print speeds. The jump is justified when daily label volumes exceed the duty cycle of lighter machines or when networked operation across multiple workstations becomes necessary. The dual-mode print engine handles both thermal transfer and direct thermal media without hardware changes.
Capacity and Media Headroom
The 4.65-inch maximum label width accommodates standard shipping, compliance and pallet labels with room for graphics and barcodes. The 10 ips throughput keeps pace with conveyor-fed workflows and batch printing peaks. The 16MB flash stores fonts, graphics and label formats locally, reducing host dependency. The printer is not suited for applications requiring higher than 203 dpi resolution or label widths beyond 4.65 inches.
Highlights
- Fast 10 ips throughput keeps production lines moving
- 203 dpi resolution delivers sharp, scannable barcodes
- Dual thermal modes handle direct thermal and transfer media
- USB 2.0, Serial and Ethernet ports simplify network integration
- 16 MB flash stores fonts and formats for quick job changes
Specifications
| Brand | CITIZEN |
|---|---|
| Print Technology | Direct Thermal/Thermal Transfer Printer |
| Printer Type | Industrial |
| Print Speed | 10 ips |
| Max Resolution(B&W) | 203 dpi |
| Memory | 16MB Flash |
Questions about this item
What maximum label width fits the CL-S700II?
The printer accepts labels up to 4.65 inches wide for both thermal transfer and direct thermal printing.
Which interfaces are used to connect and configure the printer?
Connect via USB 2.0, Serial or Ethernet; install the driver, set the IP address on the network port, then calibrate the media sensor before the first print job.
When does the printhead need replacement on the CL-S700II?
The 203 dpi printhead is a wear item; replace it when print quality degrades or after the rated kilometre count is reached.
