Silver rack-mountable 24-port network switch with front ports and status LEDs

Cisco Systems, Inc.

Cisco Systems, Inc. Meraki MS355-24X-HW 24-port network switch

SKU CH-KPBN-ZWFK0

Cloud-managed 24-port switch with 8×10G, 16×1G, 4×10G expansion, 2×40G and 2×100G uplinks, stackable with UPoE

  • FormatRack-mountable
  • Network Management TypeManaged
  • Primary Port Speed100GBase-X 10GBase-T 10GBase-X 40GBase-X 10/100/1000Base-T
  • Weight12.30 lb
  • Cloud-managed configuration removes CLI complexity
  • 24 multi-gigabit ports support 802.11ax access points and servers
  • 40 G and 100 G uplinks handle campus-scale traffic
  • Physical stacking with field-replaceable power supplies and fans
  • 60 W UPoE per port powers demanding endpoints

24-port multi-gigabit access switch

The Meraki MS355-24X-HW is a managed, rack-mountable Layer 3 switch built for high-performance enterprise and campus networks. It delivers 24 ports combining eight 10G multi-gigabit and sixteen Gigabit Ethernet connections. Cloud-based management removes the need for command-line configuration, so the switch is ready once powered and connected. Uplink flexibility comes from four 10G expansion slots plus two 40G and two 100G uplink ports.

Physical installation and cloud onboarding

The 12.30 lb chassis fits standard racks and uses field-replaceable power supplies and fans for straightforward maintenance. Physical stacking is supported through the dedicated stack ports, allowing multiple units to operate as a single logical switch. Cloud onboarding only requires an internet uplink and a Meraki licence; no CLI knowledge is needed for initial setup or ongoing port management. Buyers without a Meraki cloud subscription cannot manage the device.

Port capacity and uplink headroom

Eight multi-gigabit ports provide up to 60W of UPoE power each, comfortably supporting 802.11ax wireless access points, servers and workstations. The sixteen Gigabit ports handle standard wired endpoints without oversubscription. Four 10G expansion slots and dual 40G and 100G uplinks give ample aggregation bandwidth for campus cores. Networks needing more than 24 access ports or higher port-side speeds will require additional switches.

Highlights

  • Cloud-managed configuration removes CLI complexity
  • 24 multi-gigabit ports support 802.11ax access points and servers
  • 40 G and 100 G uplinks handle campus-scale traffic
  • Physical stacking with field-replaceable power supplies and fans
  • 60 W UPoE per port powers demanding endpoints

Specifications

BrandMeraki
SeriesMS355
ModelMS355-24X-HW
FormatRack-mountable
Network Management TypeManaged
Primary Port Speed100GBase-X
10GBase-T
10GBase-X
40GBase-X
10/100/1000Base-T
Weight12.30 lb

Questions about this item

How can I verify the MS355-24X-HW is operating correctly after racking it and connecting uplinks?

After powering on, check the front-panel LEDs for solid green on all 24 ports and both 40G uplink modules; the Meraki cloud dashboard will then show the switch online with firmware current and all 24 member ports reporting link speed and PoE status.

What ships with the MS355-24X-HW and which modules or licences must be purchased separately?

The unit includes the chassis, two field-replaceable fans, one power supply, rack-mount brackets and a console cable; a second power supply, 40G or 100G uplink transceivers, stacking cables and the Meraki enterprise licence are sold separately.

Which MS355 model should I choose for 24 multi-gigabit access ports with 40G uplinks?

The MS355-24X-HW provides exactly 24 access ports — 16 at 1G and 8 at 10G — plus two dedicated 40G uplink slots and two 100G stacking ports, matching the stated requirement.
