Silver rack-mount switch, 1U height, 24 RJ-45 ports, four SFP slots

Cisco Systems, Inc.

Cisco Systems, Inc. C1200-24P-4G network switch 24 port PoE+ 4 SFP

SKU CH-48HD-K57X3 MPN C1200-24P-4G

A manageable 24-port Gigabit PoE+ switch with four SFP uplinks and a 195 W power budget for enterprise networks

  • Switch TypeManageable
  • FormatRack-mountable
  • StandardsLayer Supported: 3 Networking Standards: IEEE 802.1x IEEE 80
  • Network MediaMedia Type Supported: Optical Fiber Twisted Pair Ethernet Te
  • Uplink InterfaceTotal Number of Expansion Slots: 4.0 Expansion Slot Type: SF
  • Primary PortsTotal Number of Network Ports: 24 Uplink Port: Yes Modular:
  • Layer 3 routing enables scalable network design
  • 195 W PoE+ budget powers 24 devices directly
  • Four SFP uplink slots add fiber flexibility
  • Fanless 1U rackmount runs silent in offices
  • IEEE 802.3az cuts power draw during low traffic

24-port PoE+ switch with four SFP uplinks

The Cisco Catalyst C1200-24P-4G is a rack-mountable, manageable Gigabit Ethernet switch built for business and enterprise networks. It provides 24 RJ-45 ports that support 10/100/1000Base-T and IEEE 802.3at PoE+ with a 195 W power budget. Four SFP expansion slots add 1000Base-X fibre uplinks for linking cabinets or floors.

Suits wired LANs needing PoE+ and fibre uplinks

This unit fits offices deploying IP phones, wireless access points or cameras that draw up to 30 W per port. The Layer 3 feature set supports static routing and basic IP services for segmented networks. Buyers who need 10 GbE uplinks, a higher PoE budget, or stacking should look at other models.

195 W PoE+ budget across 24 ports

The single specification that decides fit is the 195 W PoE budget shared by all 24 RJ-45 ports. Calculate the total draw of every powered device; if the sum exceeds 195 W you must choose a switch with a larger budget or add mid-span injectors.

Highlights

  • Layer 3 routing enables scalable network design
  • 195 W PoE+ budget powers 24 devices directly
  • Four SFP uplink slots add fiber flexibility
  • Fanless 1U rackmount runs silent in offices
  • IEEE 802.3az cuts power draw during low traffic

Specifications

BrandCisco Systems, Inc
SeriesCatalyst
Part NumberC1200-24P-4G
Switch TypeManageable
FormatRack-mountable
StandardsLayer Supported:
3
Networking Standards:
IEEE 802.1x
IEEE 802.3az
IEEE 802.3ad
IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3z
IEEE 802.3x
IEEE 802.1D
IEEE 802.1w
IEEE 802.1s
IEEE 802.3af
IEEE 802.3at
IEEE 802.1p
IEEE 802.11ac
IEEE 802.1Q
IEEE 802.1ab
Network MediaMedia Type Supported:
Optical Fiber
Twisted Pair
Ethernet Technology:
Gigabit Ethernet
Network Technology:
1000Base-X
10/100/1000Base-T
Uplink InterfaceTotal Number of Expansion Slots:
4.0
Expansion Slot Type:
SFP (mini-GBIC)
Shared SFP Slot:
Yes
Number of SFP Slots:
4
Primary PortsTotal Number of Network Ports:
24
Uplink Port:
Yes
Modular:
Yes
Network (RJ-45):
Yes
Port/Expansion Slot Details:
24 x Gigabit Ethernet PoE+
4 x Gigabit Ethernet Expansion Slot
PowerPoE (RJ-45) Port:
Yes
PoE Budget:
195 W
Input Voltage:
120 V AC
230 V AC
Frequency:
50 Hz
60 Hz
Power Source:
Power Supply
AC
Number of Power Supplies Installed:
1
Power Consumption:
236.40 W
DimensionsHeight:
1.7"
Width:
17.5"
Depth:
11.8"
WeightWeight (Approximate):
7.78 lb
Shipping weight5.81 kg
Package size569 × 427 × 109 mm

Questions about this item

How much heat does the 236.40 W power draw add to a rack running all day?

The switch draws 236.40 W continuously, so that amount of heat enters the rack; plan airflow for a 1U device measuring 1.7" high, 17.5" wide and 11.8" deep.

Which SFP transceivers must I already own to use the four uplink slots?

The four SFP (mini-GBIC) slots accept any standard Gigabit SFP module for 1000Base-X fibre or copper; they are shared slots, so each one used reduces available RJ-45 ports.

Will my older 10/100 devices and IEEE 802.3af phones work on the 24 PoE+ ports?

Yes, the 24 RJ-45 ports support 10/100/1000Base-T and deliver up to 195 W total PoE+ budget, backward compatible with 802.3af devices.
