Red Chemtrol pipe nipple, 3/4 inch NPT male threads both ends, three inches long, Schedule 80

Chemtrol

Chemtrol 6529 3/4" x 3" MNPT Pipe Nipple Sch 80

SKU CH-B0BG-TJJ16

Schedule 80 Kynar pipe nipple with 3/4 inch MNPT threads resists acids, bases and solvents up to 360 psi and 280 °F

  • Handles acids, bases and solvents with Chemtrol Kynar construction
  • Rated to 360 psi for demanding Schedule 80 systems
  • Operates from -20 °F to 280 °F across harsh environments
  • 3/4" MNPT threads on both ends for direct Schedule 80 connection
  • Compact 3-inch length fits tight piping runs

Chemtrol 6529 Schedule 80 pipe nipple

This Chemtrol 6529 pipe nipple is a 3-inch Schedule 80 fitting with 3/4-inch male NPT threads on both ends. It is designed for chemical-process piping that handles acids, bases and solvents in industrial or laboratory systems.

Verify thread size pressure and temperature limits

Confirm that the existing piping uses 3/4-inch NPT threads and Schedule 80 dimensions before ordering. The fitting is rated for a maximum operating pressure of 360 psi and a temperature range of -20 to 280 degrees Fahrenheit, so the system must stay within those limits.

Kynar PVDF body resists corrosion in harsh media

The red polyvinylidene fluoride body provides broad chemical resistance, allowing the nipple to join compatible valves, filters or instruments without adding metallic corrosion risk. Its male-to-male threaded ends connect directly to female NPT ports, keeping the flow path free of additional adapters.

Highlights

  • Handles acids, bases and solvents with Chemtrol Kynar construction
  • Rated to 360 psi for demanding Schedule 80 systems
  • Operates from -20 °F to 280 °F across harsh environments
  • 3/4" MNPT threads on both ends for direct Schedule 80 connection
  • Compact 3-inch length fits tight piping runs

Specifications

BrandNIBCO

Questions about this item

What comes in the box with the Chemtrol 6529 pipe nipple?

The box contains the single 3/4" x 3" Schedule 80 MNPT pipe nipple made from Chemtrol polyvinylidene. No gaskets, sealant or additional fittings are included.

Which Chemtrol 6529 size should I choose for a 3/4-inch Schedule 80 system?

Select the 3/4" nominal pipe size with 3-inch overall length; it matches Schedule 80 dimensions and provides male NPT threads on both ends.

What does the 360 psi rating mean when the nipple is installed in a chemical line?

The 360 psi maximum operating pressure applies at temperatures up to 280 °F; above that temperature the allowable pressure drops, and the minimum service temperature is -20 °F.
