Century OLE1036A 1/3 hp condenser fan motor, open frame, silver finish

CENTURY

CENTURY OLE1036A 1/3 hp condenser fan motor

SKU CH-957T-PM9PC

A 1/3 hp permanent split capacitor condenser fan motor running at 1075 RPM on 115 V AC with automatic thermal protection

  • weight12.69
  • typeHigh Temperature
  • materialHAWA
  • Reliable cooling performance with 1/3 hp permanent split capacitor motor
  • Simple Lennox OEM replacement for part number 321P267
  • Four-speed operation provides flexible airflow control at 1075 RPM
  • Auto thermal protection and Class B insulation handle 40 °C ambient
  • Open air-over enclosure suits condenser applications at 115 V AC

Motor specifications and intended use

The CENTURY OLE1036A is a 1/3 hp permanent split capacitor condenser fan motor designed for single-phase 115V AC systems. It delivers a nameplate speed of 1,075 RPM with four-speed operation and a 6 A full-load current. The 48Y frame and clockwise shaft rotation suit direct-drive condenser fan replacements, particularly for Lennox equipment referencing part 321P267.

Compatibility checks before ordering

Verify that your application runs on 115V AC at 60 Hz, as the motor is not usable at 200V or 208V. Confirm the required frame size is 48Y and that the driven load rotates clockwise when viewed from the shaft end. Ensure the existing capacitor matches a permanent split capacitor design and that the mounting arrangement fits an open air-over enclosure.

Thermal protection and operating limits

The motor carries Class B insulation and automatic thermal protection for safe operation up to a maximum ambient temperature of 40 degrees C. A service factor of 1 means continuous loading should not exceed the rated 1/3 hp. The open air-over enclosure relies on airflow from the fan blade for cooling, so unobstructed ventilation is essential for normal thermal performance.

Highlights

  • Reliable cooling performance with 1/3 hp permanent split capacitor motor
  • Simple Lennox OEM replacement for part number 321P267
  • Four-speed operation provides flexible airflow control at 1075 RPM
  • Auto thermal protection and Class B insulation handle 40 °C ambient
  • Open air-over enclosure suits condenser applications at 115 V AC

Specifications

BrandCentury
weight12.69
typeHigh Temperature
materialHAWA

Questions about this item

What comes with the CENTURY OLE1036A motor and what must I purchase separately?

The box contains the 1/3 hp condenser fan motor with a 48Y frame and CWSE shaft rotation. A run capacitor, mounting hardware and any required wiring are not included and must be sourced separately.

How do I choose between the available speed and voltage options for this motor?

This model is a single-speed 1075 RPM unit rated for 115 V AC only; it is not usable at 200 V or 208 V, so there are no alternative voltage or speed versions to select.

What does the 1/3 hp rating mean once the motor is installed in my condenser unit?

At 115 V the motor draws 6 A full-load current, delivers 1075 RPM under load and is designed for continuous operation up to a 40 °C ambient temperature with automatic thermal protection.
