Canon TS-E 17mm f/4L tilt-shift lens, white barrel with red ring, manual focus, rotating shift mechanism

Canon

Canon TS-E 17mm f/4L Tilt-Shift Lens 3553B002 camera lens

SKU CH-QF1F-CT3BA MPN 3553B002

Ultra-wide tilt-shift lens with 17 mm focal length, 18 elements in 12 groups and independent tilt/shift movements up to ±6.5° and ±90° rotation

  • TypeTilt-Shift Lens
  • SpecificationsFocal Length & Maximum Aperture: 17mm 1:4 Minimum Aperture:
  • FeaturesThe widest tilt-shift lens in Canon's lineup, the TS-E 17mm
  • Widest Canon tilt-shift lens at 17 mm for expansive architectural views
  • 18 elements in 12 groups with UD glass minimise chromatic aberration
  • SWC coating reduces ghosting and flare across the frame
  • Independent tilt ±6.5° and shift with 90° rotation for precise perspective control
  • Large 67.2 mm image circle covers full-frame sensors with movements

Ultra-wide tilt-shift optic

The Canon TS-E 17mm f/4L is a manual-focus tilt-shift lens built for architectural, landscape and creative photographers who need precise perspective control on EOS Digital cameras. Its 17mm focal length delivers a 104° diagonal angle of view without movements, making it the widest tilt-shift lens in the current Canon lineup.

Mount and coverage check

Verify that your camera uses the Canon EF mount and that its sensor format falls within the 67.2mm image circle diameter. The lens requires manual focus operation and provides no electronic aperture coupling, so exposure must be set manually or via stop-down metering depending on the body.

Sustained optical performance

The 18-element, 12-group design includes UD glass and aspherical elements with SWC coating to suppress chromatic aberration, ghosting and flare during extended shooting sessions. Independent tilt and shift mechanisms rotate through 90° with refined knobs allowing up to 6.5° of tilt and 12mm of shift, maintaining consistent edge-to-edge sharpness at working apertures.

Highlights

  • Widest Canon tilt-shift lens at 17 mm for expansive architectural views
  • 18 elements in 12 groups with UD glass minimise chromatic aberration
  • SWC coating reduces ghosting and flare across the frame
  • Independent tilt ±6.5° and shift with 90° rotation for precise perspective control
  • Large 67.2 mm image circle covers full-frame sensors with movements

Specifications

BrandCanon
ModelTS-E 17mm f/4L
TypeTilt-Shift Lens
SpecificationsFocal Length & Maximum Aperture: 17mm 1:4
Minimum Aperture: f/22
Lens Construction: 18 elements in 12 groups
Diagonal Angle of View: 104° (without tilt or shift)
Image circle diameter: 67.2mm
Focus Adjustment: Manual focus, rear focusing system with focusing cam (with floating system)
Closest Focusing Distance: 0.82 ft./0.25m (maximum close-up magnification: 0.14x)
Aperture Control: EMD with 8 blade iris diaphragm, circular aperture
Max. Diameter x Length, Weight: 3.5" x 4.2" /88.9 x 106.7mm (maximum lens length), 28.9 oz./820g
FeaturesThe widest tilt-shift lens in Canon's lineup, the TS-E 17mm f/4L lens expands shooting possibilities exponentially on EOS Digital cameras. Designed with UD glass to minimize and compensate for chromatic aberrations, with a specially coated aspherical element for the highest possible glare-free image quality, this tilt-shift lens offers a diagonal angle of view of 104° on a full-frame SLR camera.
TS rotation lets users freely combine tilting and shifting within the range of +/- 90° in the direction of movement. The lens also has an improved tilt & shift knob with an enhanced range of
Shipping weight1.20 kg
Package size197 × 140 × 133 mm

Questions about this item

What comes in the box and what must be purchased separately?

The lens ships as a standalone unit. Lens caps, hood, case and any filters or tripod collars are sold separately.

How do I decide between the available versions or capacities?

Only the 17mm f/4L tilt-shift model with MPN 3553B002 is offered; there are no alternative focal lengths or aperture options to choose from.

What does the 104-degree diagonal angle of view mean when the lens is mounted on a camera?

It provides an ultra-wide 104° field of view on a full-frame sensor without any tilt or shift applied, ideal for architecture and expansive landscapes.
