Compact white sheet-fed scanner with front control panel and output tray

Canon

Canon DR-M160II document scanner 60 ppm 600 dpi

SKU CH-HG5J-WYCHH MPN DR-M160II

Sheet-fed scanner captures up to 60 pages per minute at 600 dpi with a 60-sheet automatic feeder and Hi-Speed USB 2.0

  • TypeSheet Fed
  • Element TypeOne-Line Contact Image Sensor (CMOS)
  • Light SourceRGB LED
  • Scanning SpeedUp to 60 ppm / Up to 120 ipm (Simplex / Duplex)
  • Optical Resolution600 dpi
  • Max. Document Size8.50" x 14.00" Long Document Mode: Up to 118.10"
  • Scans up to 60 pages per minute simplex
  • Duplex capture reaches 120 images per minute
  • 600 dpi optical resolution delivers sharp detail
  • 7,000 pages daily duty cycle supports heavy workloads
  • Low 1.8 W energy-saving mode cuts power use

Compact sheet-fed scanner

The Canon imageFORMULA DR-M160II is a sheet-fed document scanner built for office document management. It captures colour, greyscale or black-and-white pages at up to 600 dpi optical resolution. A Hi-Speed USB 2.0 link connects it to Windows or macOS systems. The unit handles a suggested daily volume of 7,000 pages.

Suited for front-office digitisation

This scanner fits businesses that need fast, reliable capture of standard paperwork up to 8.50" x 14.00". Long-document mode extends the length to 118.10" for special forms. Buyers who need flatbed scanning for books, fragile originals or oversized bound material should look at a different device class.

60 ppm simplex and 120 ipm duplex speed

The rated throughput of 60 pages per minute in simplex and 120 images per minute in duplex determines whether the scanner keeps pace with your batch workload. Power draw peaks at 27 W and drops to 1.8 W in energy-saving mode. Dimensions are 7.00" x 11.00" x 6.80" and weight is 7.05 lbs.

Highlights

  • Scans up to 60 pages per minute simplex
  • Duplex capture reaches 120 images per minute
  • 600 dpi optical resolution delivers sharp detail
  • 7,000 pages daily duty cycle supports heavy workloads
  • Low 1.8 W energy-saving mode cuts power use

Specifications

BrandCanon
SeriesimageFORMULA
ModelDR-M160II (0114T279)
TypeSheet Fed
Element TypeOne-Line Contact Image Sensor (CMOS)
Light SourceRGB LED
Scanning SpeedUp to 60 ppm / Up to 120 ipm (Simplex / Duplex)
Optical Resolution600 dpi
Max. Document Size8.50" x 14.00"
Long Document Mode: Up to 118.10"
Automatic Document Feeder (ADF)Yes
USB PortsHi-Speed USB 2.0
Power Consumption27 W max. (Energy Saving Mode: 1.8 W)
Operating Systems SupportedWindows XP Professional (32-bit / 64-bit)
Windows XP Home (32-bit)
Windows Vista (32-bit / 64-bit)
Windows 7 (32-bit / 64-bit)
Windows 10
Mac OS 10.7.5
Mac OS 10.8.5
Mac OS 10.9.1
FeaturesScanning Modes: Color, Grayscale, Black and White
Other Features:
Auto Color Detection, Auto Page Size Detection, Auto Resolution Setting, Background Smoothing, Character Emphasis, Color Dropout/Enhance Color, Deskew, Double-Feed Release, Feeding Retry, Folio Mode, Image Rotation, Long Document Mode, MultiStream, Pre-Scan, Prevent Bleed-Through/ Remove Background, Separation Retry, Shadow Cropping, Skip Blank Page, Text Enhancement, Text Orientation Recognition, Ultrasonic Double-Feed Detection, User Preferences
Dimensions7.00" x 11.00" x 6.80"
Weight7.05 lbs.
Shipping weight5.48 kg
Package size373 × 328 × 264 mm

Questions about this item

How often will the feed rollers and separation pad need replacing on the DR-M160II?

Canon rates the DR-M160II for a suggested daily volume of 7,000 pages; feed rollers and separation pads typically last through several hundred thousand sheets, so replacement timing depends on your actual throughput.

What limits continuous scanning on the DR-M160II before the unit must pause?

The 60-sheet automatic document feeder and the 7,000-page daily duty cycle are the first constraints; once the ADF empties or the daily volume is reached, scanning stops until you reload or wait.

How much power and heat does the DR-M160II produce when running all day?

Maximum draw is 27 W during scanning and 1.8 W in energy-saving mode, so heat output stays low even during extended batch jobs.
