Slim black Canon EF-S 24mm f/2.8 STM lens, 22.8 mm thick, 52 mm filter thread

Canon

Canon 9522B002 EF-S 24mm f/2.8 STM camera lens

SKU CH-W28V-96PD0 MPN 9522B002

Ultra-slim 24 mm f/2.8 STM lens for Canon APS-C DSLRs, 38 mm equivalent, 52 mm filter thread, 0.52 m minimum focus

  • PartSLR Lenses
  • TypeWide Angle Lens
  • ColorBlack
  • Diameter52 mm
  • CompatibilityCanon EOS
  • Focus TypeAuto Focus
  • Ultra-slim pancake design measures just 0.9 in long
  • STM motor delivers smooth, quiet autofocus for video
  • Wide f/2.8 aperture excels in low-light scenes
  • 24 mm focal length gives 38 mm equivalent on APS-C
  • 52 mm filter thread accepts common circular filters

Canon EF-S 24mm f/2.8 STM Pancake Lens

This ultra-slim wide-angle lens is built for Canon APS-C DSLR bodies. It delivers a 38 mm equivalent field of view and weighs just 0.9 in thick. The STM motor enables smooth, quiet autofocus during video recording. A 52 mm filter thread accepts standard circular filters.

Ideal for Travel and Everyday Photography

Street photographers and travellers who want a discreet, lightweight prime will appreciate the pancake profile. Videographers benefit from Movie Servo AF support and full-time manual focus override. Buyers needing zoom flexibility or a faster maximum aperture should consider other optics. Full-frame shooters cannot use this EF-S mount lens.

EF-S Mount Limits Use to APS-C Cameras

The Canon EF-S bayonet fits only APS-C format EOS DSLRs and provides a 38 mm equivalent focal length. On a full-frame body the lens will not mount and the image circle would not cover the sensor. Verify your camera uses the EF-S mount before purchasing.

Highlights

  • Ultra-slim pancake design measures just 0.9 in long
  • STM motor delivers smooth, quiet autofocus for video
  • Wide f/2.8 aperture excels in low-light scenes
  • 24 mm focal length gives 38 mm equivalent on APS-C
  • 52 mm filter thread accepts common circular filters

Specifications

BrandCanon
Model9522B002
PartSLR Lenses
TypeWide Angle Lens
ColorBlack
Diameter52 mm
CompatibilityCanon EOS
Focus TypeAuto Focus
Focal Length24 mm
Aperturef/2.8 (1 : 2.8)
Camera MountCanon EF-S
Angle of View59.10 degrees
Minimum Focus Distance0.52'
Lens Construction6 elements in 5 groups
Filter thread (Diameter)52 mm
Specifications7-blade circular aperture
AutofocusYes
Focus AdjustmentFull lens extension
FeaturesWide-angle lens for Canon APS-C cameras (equivalent to 38mm on a full-frame camera) offers an ultra-slim and lightweight design.
Slimmest and lightest lens of the EF-S series (approx. lens width is 0.9 in, or slightly wider than a U.S. nickel).
A stepping motor (STM) supports the Canon EOS Movie Servo AF function to provide smooth and quiet continuous AF during video recording, as well as when shooting photos.
Delivers outstanding image quality and excellent low-light performance.
Aspheric lens element helps you achieve a high level of image quality from the center to the periphery.
DimensionsApprox. 2.70" x 0.90" (Max. Diameter x Length)
WeightApprox. 4.4 oz.
Shipping weight0.25 kg
Package size117 × 109 × 109 mm

Questions about this item

What EF-S mount compatibility does the 24mm f/2.8 STM lens provide?

The lens uses a Canon EF-S mount for APS-C format DSLRs, giving a 38mm equivalent focal length on those cameras.

What filter thread size does the 52mm diameter lens require?

The lens has a 52mm filter thread, so standard 52mm circular filters screw directly onto the front element.

How is the STM autofocus motor engaged for Movie Servo AF?

The STM motor activates automatically when the camera is set to Movie Servo AF mode; no lens switch is needed, just select the mode on the camera body.
