Rectangular black battery pack, 58 by 36 by 14 millimetres, two wire leads

Cameron Sino HT680 replacement battery 2200mAh 3.7V

SKU CH-XB5M-5ETGQ MPN HT680

Replacement battery for rugged handheld terminals and barcode scanners, 2200 mAh at 3.7 V with built-in protection circuits

  • Longer shifts powered by 2200 mAh capacity
  • Reliable voltage stability at 3.7 V for consistent scanning
  • Fits HT680 rugged terminals and Unicare PA690 scanners
  • Safety certified with ISO 9001, RoHS and CE marks
  • Ready to install with decoded chip matching original spec

Replacement battery for rugged terminals

The Cameron Sino HT680 is a 2200 mAh lithium-ion cell rated at 3.7 V, built to replace the original pack in HT680 and PA690 series handheld computers and barcode scanners. It measures 58.40 x 36.72 x 14.10 mm and weighs 50.5 g. A decoded chip reports charge status to the host exactly like the factory unit.

Suits field workers needing a fresh power cell

Technicians maintaining fleets of HT680, HT680-9550UADG, HT680-9560UADG or Unicare PA690-3E and PA690-5C devices will find a direct fit. Buyers whose equipment uses a different voltage, capacity or connector layout should look elsewhere.

Capacity and voltage define compatibility

The 2200 mAh / 8.14 Wh rating at 3.7 V is the single figure that decides whether this cell matches the original specification. Confirm the part number on the old battery — 1400-900001G, 1400-910006G or the listed equivalents — before ordering.

Highlights

  • Longer shifts powered by 2200 mAh capacity
  • Reliable voltage stability at 3.7 V for consistent scanning
  • Fits HT680 rugged terminals and Unicare PA690 scanners
  • Safety certified with ISO 9001, RoHS and CE marks
  • Ready to install with decoded chip matching original spec

Specifications

BrandCameron Sino
ModelHT680, HT680 Rugged Handheld Terminal, HT680-9550UADG, HT680-9560UADG, HT680-9590UADG, HT680-H550UADG, HT680-H560UADG, HT680-H590UADG, HT682, Multi-Languages, PA690, PA690 Rugged Handheld Computer, PA690-0260UADG, PA690-2260UADG, PA690-3261UADG, PA690-3892QADG, PA690-3892UADG, PA690-9260UADG, PA690-9261QADG, PA690-9261UADG, PA690-9892QADG, PA690-9892UADG, PA690-H261QADG, PA690-H892WADG, PA690MCA Medical Clinical Assi, PA692, PA692-0260UMDG - WM6.5 Classic, PA692-9261UMDG, PA692-9261UMHG, PA692-98E2QMDG, PA692-98E2UMDG, PA692-98E2UMHG, PA692-H261QMDG, PA692-H261UMDG, PA692-H461UADG -

Questions about this item

Does the battery arrive ready to fit the HT680 rugged terminal or do I need extra parts?

The pack includes one 2200 mAh 3.7 V cell measuring 58.40 x 36.72 x 14.10 mm and weighing 50.5 g; no screws, tools or cables are supplied.

My device shows part number 1400-910006G — is this the correct replacement?

Yes, the battery matches part numbers 1400-900001G, 1400-900005G, 1400-910005G and 1400-910006G and fits HT680, HT680-9550UADG, HT680-9560UADG and Unicare PA690 models.

What runtime can I expect from the 2200 mAh rating in daily scanning work?

The 8.14 Wh cell delivers the same capacity as the original pack; after two to three full charge cycles it reaches its rated runtime in the HT680 terminal.
