Rectangular lithium-ion battery pack, dark plastic casing, 150 by 56 by 22 mm, connector on one end

Cameron Sino BP7217 2200mAh 7.2V Standard Battery

SKU CH-CGHS-X8CVB

Replacement lithium-ion battery for Fluke test instruments, 2200 mAh at 7.2 V with built-in protection circuits

  • Specifications150.00 x 56.00 x 22.00
  • Battery Pack150.00 x 56.00 x 22.00
  • Battery Capacity2200 milliamp_hours
  • Battery Voltage7.2 volts
  • 2200 mAh capacity powers Fluke test tools longer
  • 2 V lithium-ion matches original voltage exactly
  • 150 x 56 x 22 mm form factor fits listed models
  • ISO 9001, RoHS and CE certified for safety
  • Built-in protection guards against overcharge and short circuits

Compatible replacement for Fluke test equipment

This Cameron Sino BP7217 battery replaces the original pack in Fluke 741, 741B, 743, 743B, 863, 865, 867, 867B, DSP100 and DSP2000 models. It delivers 2200mAh at 7.2 volts with a fully decoded chip that works like the original. The pack measures 150.00 x 56.00 x 22.00 mm and weighs 256 g. ISO9001, RoHS and CE certifications are included.

Upgrade from a depleted or ageing original pack

Swap this in when the original Fluke BP7217 no longer holds a full charge or shows reduced runtime in the field. The 15.84 Wh capacity restores the meter’s specified operating time. Protection circuits guard against overcharge, over‑discharge, over‑voltage and short circuit. A new battery reaches peak performance after two or three full charge and discharge cycles.

Check your device model

Confirm the instrument is one of the listed Fluke models and that the original battery carries part number BP7217. Verify the connector matches and that the pack dimensions fit the battery compartment. Use only a quality charger; low‑grade adapters can shorten life. Do not disassemble, expose to fire or water, or store above 60 °C.

Highlights

  • 2200 mAh capacity powers Fluke test tools longer
  • 2 V lithium-ion matches original voltage exactly
  • 150 x 56 x 22 mm form factor fits listed models
  • ISO 9001, RoHS and CE certified for safety
  • Built-in protection guards against overcharge and short circuits

Specifications

BrandCameron Sino
Model741, 741B, 743, 743B, 863, 865, 867, 867B, DSP100, DSP2000
Part NumberBP7217
Specifications150.00 x 56.00 x 22.00
Battery Pack150.00 x 56.00 x 22.00
Battery Capacity2200 milliamp_hours
Battery Voltage7.2 volts

Questions about this item

Will the 150.00 x 56.00 x 22.00 mm dimensions fit my Fluke 741 battery compartment?

Yes, the pack matches the original BP7217 footprint of 150.00 x 56.00 x 22.00 mm and weighs 256 g, so it seats directly in the Fluke 741, 743, 863, 865, 867, DSP100 or DSP2000 cavity without modification.

What is the correct way to connect the decoded chip connector during installation?

Align the keyed plug with the device socket and press firmly until it clicks; the common error is stopping before the latch engages, which leaves the battery undetected by the Fluke meter.

How should I store the 7.2 V lithium-ion pack when the instrument is not used for months?

Keep it at roughly half charge in a dry place below 60 °C; avoid full discharge or leaving it on a charger indefinitely, as both accelerate permanent capacity loss.
