Rectangular nickel-zinc battery pack, silver label, 280 by 37 by 33 mm

Cameron Sino BP4S 4000mAh 4.8V NiZn Battery

SKU CH-MAGN-9QC2W

Replaces Clipsal emergency-lighting packs with a 4000 mAh 4.8 V nickel-zinc cell measuring 280.00 × 37.30 × 33.30 mm

  • Specifications280.00 x 37.30 x 33.30
  • Typenickel_zinc
  • Battery Pack280.00 x 37.30 x 33.30
  • Battery Typenickel_zinc
  • Battery Capacity4000 milliamp_hours
  • Battery Voltage4.8 volts
  • 4000 mAh nickel-zinc capacity powers emergency lighting longer
  • 8 V output matches original Clipsal specifications exactly
  • 280 × 37.3 × 33.3 mm form factor fits listed models without modification
  • ISO 9001, RoHS and CE certified for safety compliance
  • Fully decoded chip ensures plug-and-play installation like the original

Replacement battery for Clipsal emergency lighting

The Cameron Sino BP4S is a nickel-zinc pack rated at 4.8 volts and 4000 milliamp-hours, delivering 19.20 watt-hours. It fits a long list of Clipsal models including CD28, DB136, DB236, LPM70, LPM80, LPS70 and VPF series units. The pack measures 280.00 by 37.30 by 33.30 millimetres and weighs 472.0 grams. It is supplied new with ISO9001, RoHS and CE certification.

Capacity and runtime limits

At 4000 milliamp-hours the cell provides the same nominal capacity as the original Clipsal BP4S and ELB-BP4S packs, so it supports standard emergency-lighting durations for the listed fittings. The 4.5 volt nominal voltage noted in the specification sheet matches the original chemistry, so run-time will be equivalent. Systems that require higher capacity or a different voltage will not be served by this pack.

Thermal and power behaviour

Nickel-zinc chemistry operates without the memory effect of older nickel-cadmium cells and accepts normal charge cycles from the host luminaire. The manufacturer advises two or three full charge-discharge cycles before the pack reaches peak performance. No active cooling is required; the pack is designed to sit inside the sealed emergency-light housing at ambient temperatures up to 60 degrees Celsius.

Highlights

  • 4000 mAh nickel-zinc capacity powers emergency lighting longer
  • 8 V output matches original Clipsal specifications exactly
  • 280 × 37.3 × 33.3 mm form factor fits listed models without modification
  • ISO 9001, RoHS and CE certified for safety compliance
  • Fully decoded chip ensures plug-and-play installation like the original

Specifications

BrandCameron Sino
ModelLuxalite LPM70 LPM80 LPS70 LPC118 LPC218 CD28 SDIP218M FFL118M FFL218M FFL136M FFL236M VPF118
Part NumberLuxalite BP4S ELB-BP4S Clipsal BP4S ELB-BP4S
Specifications280.00 x 37.30 x 33.30
Typenickel_zinc
Battery Pack280.00 x 37.30 x 33.30
Battery Typenickel_zinc
Battery Capacity4000 milliamp_hours
Battery Voltage4.8 volts

Questions about this item

Will this BP4S 4000 mAh NiZn pack fit the Clipsal LPM70 emergency luminaire I already have installed?

Yes, the BP4S is listed as a direct replacement for the Clipsal LPM70, LPM80, LPS70 and many other models including CD28, DB136 and VPF218.

How can I confirm the battery is delivering its rated 4.8 V and 4000 mAh after installation?

After two or three full charge and discharge cycles the pack reaches its rated 4.8 V and 4000 mAh capacity; a multimeter across the terminals should read close to 4.8 V when fully charged.

Does the box include a charger or connector hardware, or must I buy those separately?

The box contains only the single BP4S NiZn battery pack; no charger, connector leads or mounting hardware are supplied.
