Rectangular nickel-zinc battery pack with green label and connector wires

Cameron Sino BP120MH 3000mAh 4.8V NiZn Battery

SKU CH-2HMG-65VGZ

Nickel-zinc 4.8 V 3000 mAh pack fits Fluke 123, 123S, 43, 43B and Scopemeter 120 analysers

  • Specifications88.16 x 43.77 x 22.42
  • Typenickel_zinc
  • Battery Pack88.16 x 43.77 x 22.42
  • Battery Typenickel_zinc
  • Battery Capacity3000.00 milliamp_hours
  • Battery Voltage4.80 volts
  • Compatible with Fluke 123 and 123S analysers
  • 3000 mAh nickel-zinc chemistry delivers 14.40 Wh
  • 8 V output matches original BP120MH specification
  • Certified to ISO 9001, RoHS and CE standards
  • Dimensions 88.16 x 43.77 x 22.42 mm fit existing bay

Replacement Battery for Fluke Test Instruments

This Cameron Sino BP120MH battery replaces the original power pack in Fluke 123, 123S, 43, 43B and Scopemeter 120 models running firmware below V2. It delivers 4.8 volts and 3000 milliamp hours capacity with a fully decoded chip that communicates like the factory unit. The pack measures 88.16 by 43.77 by 22.42 millimetres and weighs 221.6 grams.

Nickel-Zinc Chemistry Limits

Nickel-zinc cells operate at 4.8 volts nominal, higher than nickel-metal-hydride alternatives, so the instrument must be designed for this voltage. The chemistry does not suffer from memory effect, but it requires a charger programmed for the correct termination voltage. Overcharge, over-discharge, over-voltage and short-circuit protection circuits are built into the pack to protect both the cells and the analyser.

Capacity and Runtime Headroom

At 14.40 watt-hours the pack powers a typical power-quality analyser or scopemeter through extended field sessions. Runtime falls when the analyser drives its backlight, acquisition memory or communication modules continuously. The battery reaches peak capacity after two or three full charge-discharge cycles. It is not suited for instruments that require a different voltage, form factor or higher watt-hour rating.

Highlights

  • Compatible with Fluke 123 and 123S analysers
  • 3000 mAh nickel-zinc chemistry delivers 14.40 Wh
  • 8 V output matches original BP120MH specification
  • Certified to ISO 9001, RoHS and CE standards
  • Dimensions 88.16 x 43.77 x 22.42 mm fit existing bay

Specifications

BrandCameron Sino
ModelFluke 123 ( Firmware below V2., Fluke 123S ( Firmware below V2, Fluke 43 Power Quality Analyze, Fluke 43B Power Quality Analyz, Quality Analyzer 43, Quality Analyzer 43B, Scope Meter BP123, Scope Meter BP124, Scopemeter 120
Part NumberB11483, BP120
Specifications88.16 x 43.77 x 22.42
Typenickel_zinc
Battery Pack88.16 x 43.77 x 22.42
Battery Typenickel_zinc
Battery Capacity3000.00 milliamp_hours
Battery Voltage4.80 volts

Questions about this item

Which Fluke model numbers does the BP120MH 3000mAh 4.8V NiZn battery replace?

The BP120MH replaces Fluke 123 (firmware below V2), 123S (firmware below V2), 43 Power Quality Analyzer, 43B Power Quality Analyzer and Scopemeter 120 when the original part number is B11483 or BP120.

What runtime does the 3000mAh 14.40Wh capacity deliver in a Fluke analyzer?

The 3000mAh 14.40Wh pack powers compatible Fluke scopes and analyzers at 4.8V; actual run time depends on the instrument's current draw and measurement mode.

Does the nickel-zinc chemistry require a specific charger interface or voltage limit?

The battery includes a decoded chip that matches the original Fluke charging circuit; use only the Fluke-approved charger to maintain the 4.8V nominal voltage and protection features.
