Small rectangular replacement battery with rounded edges, light-coloured plastic casing, two-pin connector visible

Cameron Sino Battery for Morita EndoSync 800mAh 2.96Wh

SKU CH-VNJE-XM48K

Replacement battery for Morita and Brasseler endodontic handpieces, 800 mAh at 3.7 V with overcharge and short-circuit protection

  • Replaces original Morita battery in EndoSync handpiece
  • 800 mAh capacity delivers 2.96 Wh runtime
  • 7 V output matches factory specification exactly
  • ISO 9001, RoHS and CE certified for medical use
  • Compact 51.56 x 14.40 x 14.40 mm fits existing compartment

Direct Replacement Battery

This Cameron Sino battery replaces the original Morita 7505626, 7505628 and RB-CB1003 packs. It fits Brasseler EndoSync, Pencure LED, TR-CM, TriAuto mini Endo Motor Handpi, TR-ZX2 and VL-7 handpieces. The new fully decoded chip works just like the original. Installation is straightforward with guides available online.

Upgrade From Worn Cells

The jump is worth it when the original pack no longer holds a full day of charge or shows reduced run-time during procedures. A fresh 800mAh cell restores the intended 3.7V output and 2.96Wh capacity. Overcharge, over-discharge, over-voltage and short-circuit protection help extend the new pack's service life.

Clinical Session Capacity

The 800mAh capacity comfortably handles typical endodontic sessions without needing a mid-procedure swap. It runs out during extended back-to-back treatments or if the handpiece is left on standby for long periods. Dimensions of 51.56 x 14.40 x 14.40mm and 20.6g weight match the original enclosure exactly.

Highlights

  • Replaces original Morita battery in EndoSync handpiece
  • 800 mAh capacity delivers 2.96 Wh runtime
  • 7 V output matches factory specification exactly
  • ISO 9001, RoHS and CE certified for medical use
  • Compact 51.56 x 14.40 x 14.40 mm fits existing compartment

Specifications

BrandCameron Sino
ModelBrasseler EndoSync, Pencure LED, TR-CM, Tri Auto ZX, TriAuto mini Endo Motor Handpi, TriAuto ZX2, TR-ZX2, VL-7

Questions about this item

What are the exact dimensions of this replacement battery for the Morita EndoSync handpiece?

The battery measures 51.56 mm in length and 14.40 mm in both width and height, matching the original specifications for the EndoSync, Pencure LED and TriAuto models.

How do I correctly connect the battery connector during installation?

Align the decoded chip connector with the handpiece socket and press firmly until seated; the most common error is a partial connection that prevents the device from recognising the new battery.

When should I replace this 800mAh battery in my EndoSync handpiece?

Replace the pack when run-time drops noticeably or the handpiece fails to hold a charge after a full cycle; the built-in protection circuit guards against over-charge and short circuits during its service life.
